DEMO MANUAL DC2268A-F
parts List
ITEM
QTY
REFERENCE
Required Circuit Components
1
6
CIN1, CIN2, CIN3, CIN4, CIN5, CIN6
2
2
CO1, CO5
3
4
CO2, CO3, CO4, CO6
4
1
C6
5
2
C7, C15
6
2
C8, C14
7
2
C5, C12
8
2
C16, C17
9
2
C18, C20
10
1
L1
11
2
R2, R22
12
3
R3, R5, R14
13
1
R4
14
2
R6, R17
15
1
R7
16
1
R9
17
2
R10, R16
18
1
R15
19
1
R18
20
3
R24, R25, R30
21
1
U1
Additional Demo Board Circuit Components
1
0
C1, C2, C3, C4, C9, C10, C11, C13
2
0
R1, R8, R11, R12, R13, R19, R20, R21,
R23, R26, R27, R28, R29
3
0
R31, R32
Hardware: For Demo Board Only
1
1
J1
6
PART DESCRIPTION
CAP , 1210 22µF 10% 25V X5R
CAP , 7343 330µF 20% 6.3V POSCAP
CAP , 1210 100µF 10% 6.3V X5R
CAP , 0603 4.7µF 20% 6.3V X5R
CAP , 0603 68pF 5% 50V C0G / NP0
CAP , 0603 0.1µF 10% 25V X7R
CAP , 0603 3300pF 5% 16V C0G
CAP , 0603 10µF 20% 25V X5R
CAP , 0603 22µF 20% 6.3V X5R
IND, 1.0µH
RES, 0603 0Ω JUMPER
RES, 0603 100Ω 5% 0.1W
RES, 0603 121kΩ 1% 0.1W
RES, 0603 10kΩ 5% 0.1W
RES, 0603 13.3kΩ 1% 0.1W
RES, 0603 0Ω
RES, 0603 10kΩ 1% 0.1W
RES, 0603 143kΩ 1% 0.1W
RES, 0603 19.1kΩ 1% 0.1W
RES, 0603 10Ω 5% 0.1W
IC, VOLTAGE REGULATOR LGA
CAP , 0603 OPTION
RES, 0603 OPTION
RES, 2512 OPTION
CONN., CARD EDGE 1.6mm
MANUFACTURER/PART NUMBER
AVX 12103D226KAT2A
PANASONIC 6TPF330M9L
AVX 12106D107KAT2A
AVX 06036D475MAT2A
AVX 06035A680JAT2A
AVX 06033C104KAT2A
AVX 0603YC332JAT2A
TDK C1608X5R1E106M080AC
TDK C1608X5R0J226M080AC
COILCCRAFT XAL5030-102MEC
VISHAY CRCW06030000Z0EA
VISHAY CRCW0603100RJNEA
VISHAY CRCW0603121KFKEA
VISHAY CRCW060310K0JNEA
VISHAY CRCW060313K3FKEA
VISHAY CRCW06030000Z0EA
VISHAY CRCW060310K0FKEA
VISHAY CRCW0603143KFKEA
VISHAY CRCW060319K1FKEA
VISHAY CRCW060310R0JNEA
LINEAR TECH. LTM4628EV#PBF
OPTION
OPTION
OPTION
SAMTEC MEC2-20-01-L-DV--TR
dc2268aff
