Parts List - Analog Devices DC1717B Demo Manual

PARTS LIST

ITEM QTY REFERENCE
1 0 C1, C3, C5, C8
2 0 C2, C4, C6, C9
3 1 C7
4 5 C10, C11, C12, C13, C15
5 1 C14
6 1 C16
7 3 C17, C18, C19
8 3 C20, C21, C22
9 3 D1, D2, D3
10 0 D7
11 8 D8-D12, D16, D17, D18
12 3 D13, D14, D15
13 9 E1-E4, E6, E13-E16
14 6 E7, E8, E9, E10, E11, E12
15 3 JP1, JP2, JP3
16 3 SHUNTS ON JP1-JP3 (1&2)
17 6 J1, J2, J3, J4, J5, J6
18 3 Q1, Q2, Q3
19 0 Q4, Q5, Q6, Q7, Q8, Q9
20 1 Q10
21 1 Q11
22 1 R4
23 3 R5, R8, R12
24 3 R6, R9, R13
25 1 R7
26 1 R10
27 1 R11
28 7 R14-R16, R20-R22, R29
29 0 R17
30 0 R18
31 1 R19
32 3 R23, R26, R28
33 5 R30, R31, R32, R33, R36
34 1 R34
35 1 R35
36 1 U1
37 3 U2,U3,U5
38 1 U4
39 4 MH1-MH4
DEMO MANUAL DC1717B
PART DESCRIPTION
CAP., 1206
CAP., 2220
CAP., ALUM., 47µF 50V 20% SMT
CAP., X5R, 1µF 50V, 10%, 0603
CAP., X5R 10µF 10V 20% 0805
CAP., NPO 10nF 50V 5% 0805
CAP., X5R 0.1µF 50V 10% 0805
CAP., X7R 0.047µF 50V, 10%, 0805
DIODE, TVS BI-DIRECTIONAL, 26V, 600W
ZENER DIODE, 5.1V SOD-123
LED, GREEN, LED-ROHM-SML-01
DIODE, SCHOTTKY, SOD323
TURRET, 0.094"
TURRET, 0.063"
HEADERS, SGL. ROW 3 PINS 2mm CTRS.
SHUNT, 2mm CTRS.
JACK, BANANA
MOSFET 2P-CH 40V 8A 8SO
MOSFET P-CHAN., 40V, FDD4685, DPAK
XTOR N-CHAN., SOT23
XTOR N-CHAN., SOT23
RES., CHIP 1.69M 0.125W 1% 0805
RES., CHIP 69.8k 0.125W 1% 0805
RES., CHIP 130k 0.125W 1% 0805
RES., CHIP 590k 0.125W 1% 0805
RES., CHIP 1.05M 0.125W 1% 0805
RES., CHIP 127k 0.1W 1% 0603
RES., CHIP 1k 0.1W 5% 0603
RES., CHIP 845k 0.1W 1% 0603
RES., CHIP 115k 0.06W 1% 0603
RES., CHIP 30.9k 0.1W 1% 0603
RES., CHIP 249 0.1W 1% 0603
RES., CHIP 100k 0.1W 5% 0603
RES., CHIP 68k 0.25W 5% 1206
RES., CHIP 240Ω 0.25W 1% 1206
I.C., POWERPATH CONTROLLER, QFN24UF-4×4
I.C., TRIPPLE 3-INPUT NOR GATE TSSOP14
I.C., LOW DROPOUT REG. TSOT23-8
STANDOFF, NYLON, 0.50, 1/2"
MANUFACTURER/PART NUMBER
OPT
OPT
SUN ELECT., 50CE47BS
TAIYO YUDEN UMK107BJ105KA-T
TAIYO YUDEN LMK212ABJ106MG-T
NIC, NMC0805NPO103J50TRPF
TAIYO YUDEN UMK212BJ104KG-T
MURATA, GRM21BR71H473KA01L
DIODES/ZETEX SMBJ26CA-13-F
OPT
ROHM, SML-012P8TT86
VISHAY SEMI., BAT42WS-E3-08
MILL-MAX 2501-2-00-80-00-00-07-0
MILL-MAX 2308-2-00-80-00-00-07-0
SAMTEC TMM-103-02-L-S
SAMTEC 2SN-BK-G
KEYSTONE 575-4
VISHAY Si4909DY-T1-GE3
OPT
DIODE INC., MMBTA42-7-F
DIODE INC., MMBT3904-7-F
VISHAY, CRCW08051M69FKEA
VISHAY, CRCW080569K8FKEA
NIC, NRC10F1303TRF
VISHAY, CRCW0805590KFKEA
VISHAY, CRCW08051M05FKEA
VISHAY, CRCW0603127KFKED
VISHAY, CRCW06031K00JNEA
OPT
OPT
VISHAY, CRCW060330K9FKEA
VISHAY, CRCW060249RFKEA
NIC, NRC06J104TRF
NIC, NRC12J683TRF
VISHAY, CRCW1206240RFKEA
LINEAR TECH CORP. LTC4417CUF
NXP/PHILIPS SEMI. 74HC27PW
LINEAR TECH CORP. LT3060ETS8-5
KEYSTONE, 8833 (SNAP ON)
Rev 0
7
