Unvented Gas
Cast Iron Stove
Single Door Models:
CSVF20SNV CSVF30SNV
CSVF20SPV CSVF30SPV
Double Door Models:
VFCS20DNV VFCS30DNV
VFCS20DPV VFCS30DPV
Installation & Operating
Instructions
WARNINGS
If the information in this manual is not
followed exactly, a fire or explosion may
result causing property damage, personal
injury or loss of life.
– Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
– Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
586002
csvf vfcs cover
This appliance may be installed in an
a f t e r m a r k e t , p e r m a n e n t l y l o c a t e d ,
manufactured (mobile) home, where not
prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases.
This is an unvented gas-fired heater. It uses air
(oxygen) from the room in which it is installed.
Provisions for adequate combustion and
ventilation air must be provided. Refer to page
7.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future refer-
ence.
O N
O FF
58D6002 1/13 Rev. 10
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vermont Castings CSVF20SNV
Summary of Contents for Vermont Castings CSVF20SNV
- Page 1 Unvented Gas Cast Iron Stove O FF Single Door Models: CSVF20SNV CSVF30SNV CSVF20SPV CSVF30SPV Double Door Models: VFCS20DNV VFCS30DNV VFCS20DPV VFCS30DPV Installation & Operating Instructions WARNINGS 586002 If the information in this manual is not csvf vfcs cover followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
Unvented Cast Iron Gas Stoves PLEASE READ THE INSTALLATION & OPERATING INSTRUCTIONS BEFORE USING APPLIANCE. Thank you and congratulations on your purchase of a Vermont Castings Group stove. IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty. -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION Unvented Cast Iron Gas Stoves OWNER INSTALLER Please retain these instructions for future reference. Please leave these instructions with the appliance. • Any change to this heater or its controls can be dangerous. • Improper installation or use of the heater can cause serious injury or death from fire, burns, explosion or carbon monoxide poisoning. - Page 4 IMPORTANT SAFETY INFORMATION Unvented Cast Iron Gas Stoves Continued from page 3 tion. This is a normal and temporary occurrence. Proposition 65 Warning: Fuels used in gas, woodburn- The initial break-in operation should last two to three ing or oil fired appliances, and the products of combus- hours with the burner at the highest setting.
-
Page 5: Product Features
OFF with remote switch. Max.Input Min. Input LOW/HI - Variable position to control flame Model Fuel Control BTU/h BTU/h height (heat output). Both front and CSVF20SNV Nat. Millivolt 10,000 6,000 rear burners are in operation to pro- CSVF20SPV Millivolt 10,000 6,000 vide realistic glow and yellow flame. -
Page 6: Stove Dimensions
DIMENSIONS Unvented Cast Iron Gas Stoves Figure 3 - Stove Dimensions Ref. CSVF20S / VFCS20D CSVF30S / VFCS30D 586002 21Z\v" 26C\v" CSVF dims 23" 28Z\x" 16Z\x" 19C\v" 20Z\v" 23C\v" 58D6002... -
Page 7: Getting Started
GETTING STARTED Unvented Cast Iron Gas Stoves Gloves are recommended when handling ceramic fiber logs to prevent skin irritation from loose fibers. Logs are fragile — handle with care. AVAILABLE COLORS Carefully inspect the contents for shipping damage. If any parts are missing or damaged, immediately inform the Graphite dealer from whom you purchased the appliance. -
Page 8: Clearances / Height Requirements
CLEARANCES and HEIGHT REQUIREMENTS Unvented Cast Iron Gas Stoves The dimensions shown in Figure 4 are minimum clearances to maintain in installing this heater. Left and right clearances are determined when facing the front of the heater. Follow these instructions carefully to ensure safe installation. Failure to follow instructions exactly can create a fire hazard. - Page 9 CLEARANCES and HEIGHT REQUIREMENTS Unvented Cast Iron Gas Stoves ST1171 Figure 5 - Alcove Installation Tested Minimum Alcove Dimensions ST1171 Height alcove clearances from Hearth Width Depth Model CSVF20/VFCS20 38Z\x" 23" 36" CSVF30/VFCS30 52" 34" 36" NOTE: Maintain minimum side and back clearances when placing stove in alcove.
-
Page 10: Remove Unit From Crate
INSTALLATION Unvented Cast Iron Gas Stoves Hearth REMOVE UNIT FROM CRATE Door 1. Remove two (2) straps. Figure 6 2. Open plastic bag and slide to bottom of unit. Figure 7 3. Lift up on ash lip and pivot down to open control door. Figure 8 4. -
Page 11: Connect Gas Line
CONNECT GAS LINE Unvented Cast Iron Gas Stoves NOTICE: A qualified gas appliance installer must connect the heater to the gas supply. Consult all local IMPORTANT: Hold heater valve firmly with a wrench to codes. prevent movement when connecting to inlet pipe. Use new black iron or steel pipe. -
Page 12: Check Gas Pressure
CHECk GAS PRESSURE and CONNECT REMOTE RECEIVER Unvented Cast Iron Gas Stoves The heater gas inlet connection is 3/8" NPT at the valve. CONNECT REMOTE RECEIVER The inlet is located on left side of stove. Remove front 1. Remove cover on control panel to show opening control plate to better access the inlet. -
Page 13: Electrical Wiring
ELECTRICAL WIRING (MILLIVOLT) Unvented Cast Iron Gas Stoves The millivolt valve is a self-powered combination gas control THAT DOES NOT REQUIRE ODS Pilot 110V AC TO OPERATE. Label all wires prior to On/Off d i s c o n n e c t i o n w h e n Switch servicing controls. -
Page 14: Log And Rock Wool Placement
LOG and ROCk WOOL PLACEMENT Unvented Cast Iron Gas Stoves The positioning of the logs is critical to the safe and clean operation of this heater. Sooting and other problems may result if the logs are not properly and firmly positioned in the appliance. -
Page 15: Csvf30 / Vfcs30
LOG PLACEMENT Unvented Cast Iron Gas Stoves The positioning of the logs is critical to During initial operation of the new heater, the safe and clean operation of this heater. burning logs will give off a paper burning Sooting and other problems may result if the smell and orange flames will be present. -
Page 16: Flame Appearance
FLAME APPEARANCE Unvented Cast Iron Gas Stoves Flames from the pilot, front and rear burner should be BURNER FLAME visually checked as soon as the heater is installed. In addition, periodically check the flames visually during In normal operation at full rate after 15 minutes, the operation. -
Page 17: Operating Instructions
OPERATING INSTRUCTIONS Unvented Cast Iron Gas Stoves OPERATING INSTRUCTIONS Avoid any drafts that alter burner flame patterns. Do not allow fans to blow directly into the stove. Do not place a blower inside the burn area of the stove. Ceiling fans may create drafts that alter flame patterns. -
Page 18: For Your Safety Read Before Lighting
OPERATING INSTRUCTIONS Unvented Cast Iron Gas Stoves FOR YOUR SAFETY READ BEFORE LIGHTING If you do not follow these instruction exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance is equipped with an ignition •... -
Page 19: Millivolt Control Lighting Instructions
OPERATING INSTRUCTIONS Unvented Cast Iron Gas Stoves MILLI-VOLT CONTROL LIGHTING INSTRUCTIONS 1. STOP! Read the safety information label. 7. With the control knob pushed in, push in and release the piezo ignitor button to light the 2. Make sure the manual shutoff valve is fully pilot. -
Page 20: Match Lighting Instructions
OPERATING INSTRUCTIONS / CLEANING and SERVICING Unvented Cast Iron Gas Stoves MATCH LIGHTING INSTRUCTIONS 1. Open stove door. Remove any items neces- 3. After control knob has been released and pilot sary for easy access to the pilot (for example: stays lit, reinstall any items that were removed logs, screens, etc.). -
Page 21: Troubleshooting
TROUBLESHOOTING Unvented Cast Iron Gas Stoves NOTE: All troubleshooting items are listed in order of Turn appliance OFF and allow to cool operation. before servicing. Only a qualified service person should service and repair the heater. POSSIBLE CAUSE OBSERVED PROBLEM REMEDY When ignitor button is pressed, 1. - Page 22 Unvented Cast Iron Gas Stoves TROUBLESHOOTING If the gas quality is bad, your pilot may not stay lit, the burners may produce soot and the heater may backfire when lit. If the gas quality or pressure is low, contact your local gas supplier immediately.
-
Page 23: Replacement Parts
REPLACEMENT PARTS Unvented Cast Iron Gas Stoves BURNER ASSEMBLY CSVF20 / VFCS20 586002 CSVF VFCS20 PARTS Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. - Page 24 REPLACEMENT PARTS Unvented Cast Iron Gas Stoves BURNER ASSEMBLY CSVF20SNV CSVF20SPV Ref. Description Qty. VFCS20DNV VFCS30DPV Piezo Ignitor 14D0503 14D0503 VF Valve Tube 58D0519 58D0519 Peizo Wire 00K0632 00K0632 Burner 33D0070 33D0071 Control Valve 14D0467 14D0468 Burner Injector 33D0280 33D0281...
-
Page 25: Csvf30/Vfcs30 Burner Assembly
REPLACEMENT PARTS Unvented Cast Iron Gas Stoves BURNER ASSEMBLY CSVF30 / VFCS30 Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this 586002 appliance may result in property damage or CSVF VFCS 30 parts personal injury. - Page 26 REPLACEMENT PARTS Unvented Cast Iron Gas Stoves BURNER ASSEMBLY CSVF30SNV CSVF30SPV Ref. Description Qty. VFCS30DNV VFCS30DPV Piezo Ignitor 14D0503 14D0503 5/16 Union Tee 43D0181 43D0181 Piezo Wire 00K0632 00K0632 Front Burner 58D0193 58D0193 Rear Burner 58D0435 58D0435 Control Valve 14D0467 14D0468 Front Burner Injector 58D0061...
-
Page 27: Csvf30/Vfcs30 Logs
REPLACEMENT PARTS Unvented Cast Iron Gas Stoves 586002 CSVF VFSC 30 logs CSVF30 / VFCS30 LOGS Ref. Description Qty. Part No. Back Log #1 58D1901 Bottom Left Log #2 58D1902 Bottom Right Log #3 58D1903 Left Top Log #4 58D1904 Right Top Log #5 58D1905 Failure to position the parts in accordance with these diagrams or failure to use... - Page 28 Unvented Cast Iron Gas Stoves 58D6002...
- Page 29 Unvented Cast Iron Gas Stoves 58D6002...
-
Page 30: Massachusetts Residents Only
Requirements for the Commonwealth of of eight (8) feet above grade directly in line with the exhaust Unvented Cast Iron Gas Stoves vent terminal for the horizontally vented gas fueled heating Massachusetts appliance or equipment. The sign shall read, in print size no This product must be installed by a licensed plumber or less than one-half (1/2) inch in size, “GAS VENT DIRECTLY gas fitter when installed within the Commonwealth of... -
Page 31: Warranty
Limited Lifetime Warranty Vermont Castings Group warrants its products to be free of defects in material and workmanship and backs each product with a Limited Lifetime Warranty. This warranty is to the original purchaser of a Vermont Castings Group product and is not transferable. - Page 32 Vermont Castings Group 149 Cleveland Drive • Paris, Kentucky 40361 www.vermontcastingsgroup.com...
