• Do not put your fingers into the notches or in position
where they can get cut.
• Do not touch the blade unless you remove the battery
pack.
• Do not use the machine if the blade is damaged or bent.
• Remove all objects such as cords, lights, wire, or string
which can become entangled in the cutting blade and
create a risk of personal injury.
WARNING
If the blade jams on an electrical cord or line, DO NOT
TOUCH THE BLADE! IT CAN BE LIVE AND
DANGEROUS. Do the steps below:
1. Hold the insulated rear handle or put the machine down
and away from you.
2. Disconnect the electrically service to the damaged line
or cord before you try to free the blade.
4.1

START THE MACHINE

Figure 4
1. Remove the scabbard.
2. Press the safety lock button using your thumb and at the
same time squeeze the trigger.
WARNING
Hold the machine with hands during operation.
If the machine accidentally falls,it will stop and the blade
will fully stop after a few seconds. The machine will then
locks OFF.
4.2

STOP THE MACHINE

1. Release the trigger to stop the machine.
4.3

OPERATION TIPS

• Start by trimming the top of the hedge. Slightly tilt the
tool (up to 15° relative to the line of cut) so that the blade
tips point slightly towards the hedge. This will cause the
blades to cut more effectively. Hold the tool at the desired
angle and move it steadily along the line of cut. The
doublesided blade allows you to cut in either direction.
• In order to obtain a very straight cut, stretch a piece of
string along the length of the hedge at the desired height.
Use the string as a guideline, cutting just above it.
• In order to obtain flat sides, cut upwards with the growth.
Younger stems move outwards when the blade cuts
downwards, causing shallow patches in the hedge.
• Take care to avoid any foreign objects. Especially avoid
hard objects such as metal wire and railings, as these
could damage the blades.
• Regularly oil the blades.
NOTE
English
Keep hands away from blade while operating. Contact with
blade will result in serious personal injury.
5

MAINTENANCE

Do not let brake fluids, gasoline, petroleum-based materials
touch the plastic parts. Chemicals can cause damage to the
plastic, and make the plastic unserviceable.
Do not use strong solvents or detergents on the plastic
housing or components.
Remove the battery pack from the machine before
maintenance.
5.1

CLEAN THE MACHINE

Keep the machine and the motor free of leaves, branches or
excessive oil to prevent fire risks.
• Use a moist cloth with a mild detergent to clean the
machine.
• Clean all moisture with a soft dry cloth.
• Use a small brush to clean the air vents.
5.2

LUBRICATE THE BLADE

To increase the efficiency and life of the blades, lubricate
them carefully after each work session:
• Put the machine on a flat and smooth surface.
• Use a soft cloth to clean the blades and a brush to remove
more dirt.
• Use a light layer of oil to lubricate the blades along the
top edge of the blade.
We recommend to use the non-pollutant type oil.
6

STORE THE MACHINE

Clean the machine before storage.
1. Remove the battery pack.
2. Attach the scabbard (optional).
3. Cool the motor.
4. Check that there are no loose or damaged components. If
it is necessary, replace the damaged components, tighten
5
WARNING
CAUTION
CAUTION
WARNING
WARNING
NOTE
NOTE
EN
