SMC Networks CUJ Series Manual page 3

CUJ
Series
Concentrates wiring and
piping on one surface
Allows more efficient installation, since four
directions can be used freely.
Easy seal replacement
Seals can be replaced easily just by removing
the rod cover.
Rod cover
Two auto
switches
can be installed
even for 4mm
strokes.
Series Variations
Bore size
Series
(mm)
4
Single acting (spring return)
6
Single acting (spring return)
CUJ
8
Single acting (spring return)
10
Single acting (spring return)
ø4, ø6, ø8, ø10
Free-mount design
allows installation from
four directions.
Solid state switch
Model D-F8
Action
4 6
b b
Double acting
b b
b b
Double acting
b b
b b
Double acting
b b
b b
Double acting
b b
Clean room series
Series 10-, 11-CUJ
Stroke (mm)
Clean room
series
8 10 15 20
b b
b b b
b
b b b b
b b
b b b b
b b
Fine pitch
mounting is
possible.
E
Pitch dimensions
(without magnet)
Bore Size
4
6
8
10
With front boss (h9)
Centering can be done easily.
Rod end
Auto switch
configuration
Male thread
Nil
Without thread
b
Solid state
b Female thread
switch
D-F8
Male thread
D-F9
b
(mm)
E
10
13
13
13.5
2
Features
