SMC Networks CUJ Series Manual page 14

Series
Auto Switch Common Specifications
Auto Switch Common Specifications
Type
Operating time
Impact resistance
Insulation resistance
Withstand voltage
Ambient temperature
Enclosure
Lead Wire Lengths
How to specify lead wire length
(Example)
D - F9P
Note 1) Lead wire length Z: Auto switch applicable to 5m length
Solid state switches: All models produced upon receipt of order (standard procedure).
Note 2) For solid state with flexible wire specification, add "-61" after the lead wire length.
D - F9PL -
61
(Example)
b Flexible specification
11
CUJ
50MΩ or more at 500VDC (between lead wire and case)
L
Lead wire length
b
Nil 0.5m
L 3m
Z 5m
Solid state switch
1ms or less
1000m/s²
1000VAC for 1min.
(between lead wire and case)
–10 to 60°C
IEC529 standard IP67,
JISC0920 watertight construction
Lead Wire Color Changes
Lead wire colors of SMC auto switches have been changed as shown in the
tables below starting from production in September 1996, in order to meet the
IEC947-5-2 standard.
Take special care regarding wire polarity during the time when the old colors still
coexist with the new colors.
2 wire
Old New
Output (+) Red Brown
Output (–) Black Blue
3 wire
Old New
Power supply (+) Red Brown
Power supply GND Black Blue
Output White Black
