1 INTRODUCTION

Important information: Read the manual carefully before using this device.
Inappropriate utilization may cause damage to the device, to the DUT (device under test), and/or other
components of your setup.
Keep these instructions in a safe place and pass them on to any future user.
1.1

Conformity

We, Image Engineering GmbH & Co. KG, hereby declare that the CAL4-E corresponds to the essential
requirements of the following EC directive in its current version:
•
Electromagnetic Compatibility - 2014/30/EU
1.2

Intended use

The integrating sphere is designed to measure color, resolution, OECF, dynamic range, and noise when using
the endoscopy light source.
•
Only suitable for indoor use.
•
Place your system in a dry, constant tempered environment without light interference.
•
The optimal ambient temperature range is 22 to 26 degrees Celsius.
1.3

General safety information

•
Do not look directly at the open sphere or light source when using high intensities.
•
Do not open the device without prior instructions from the Image Engineering support team.

2 GETTING STARTED

2.1

Scope of delivery

•
CAL4-E – 30 cm integrating sphere (without light source)
•
Four adapters for various types of endoscopes
•
High temperature resistant cold-light cable, XENON approved

3 OPERATING INSTRUCTIONS HARDWARE

3.1

Requirements

•
Endoscope
•
Projector
Image Engineering
