1 INTRODUCTION

Important information: Read the manual carefully before using the device.
Inappropriate utilization may cause damage to the device.

Conformity

We, Image Engineering GmbH & Co. KG, hereby declare that GEOCAL/GEOCAL XL corresponds to the
essential requirements of the following EC directives:
- 2011/65/EU - RoHS 2
- 2014/35/EU - Low Voltage
- 2014/30/EU - Electromagnetic Compatibility
And standards or normative documents:
EN 61326-1:2013 – Electrical equipment for measurement, control, and laboratory use - EMC
-
requirements - Part 1: General requirements
- EN 61000-3-2:2014 - Electromagnetic compatibility (EMC) - Part 3-2: Limits - Limits for harmonic
current emissions
- EN 61000-3-3:2013 - Electromagnetic compatibility (EMC) - Part 3-3: Limits
- EN 62471-2:2009 - Photobiological safety of lamps and lamp systems
- DIN EN 60825-1 - Safety of laser products - Part 1: Equipment classification and requirements

Intended use

GEOCAL/GEOCAL XL consists of an illuminating hardware device and software for geometric calibration
of camera systems. The GEOCAL software is used for calculating the calibration parameters from a
single image taken with a camera system of the point grid generated by the GEOCAL hardware device.
•
Only suitable for indoor use.
•
Place the system in a dry and constant tempered environment. Avoid high air humidity.

General safety information

WARNING! GEOCAL / GEOCAL XL uses a laser diode for illumination.
LASER RADIATION CLASS 1M LASER PRODUCT
•
•
•
Image Engineering
Do not stare into the beam
Do not view directly with optical instruments
Do not open the housing of GEOCAL / GEOCAL XL under any circumstances
