AP305C/CX Overview

AP305C/CX Features

The access points have the following features:
•
Radios – two built-in dual-band radios
•
Kensington® lock
•
ETH0 Ethernet port – autosensing 10/100/1000G BASE-T/TX Mbps, with IEEE 802.3af or 802.3at
compliant Power over Ethernet (PoE), and requires a Cat5 cable
•
Antennas:
◦
AP305C – four internal omnidirectional 2.4 GHz/5 GHz dual-band antennas
◦ AP305CX – four external omnidirectional 2.4 GHz/5 GHz dual-band antennas
One dual-band antenna is shared between Wi-Fi and Bluetooth Low Energy (BLE)
•
Power source – 802.3af and 802.3at power over Ethernet injector
•
Trusted Module Platform (TPM) chip for added security
•
Operating temperature: +0 °C to +40 °C (+32 °F to +104 °F)
•
Storage temperature: −40 °C to +80 °C (−40 °F to +176 °F)
