External Antenna Configuration
Information
Details about antenna gain, external antenna configuration, and antenna radio port support.

Antenna gain

Wi-Fi/BLE antenna
2.4 GHz
5.0 GHz

External antenna information

The AP305CX access point comes with four external antenna connectors and is compatible with the
ML-2452-APA2-02 and AH-ACC-ANT-AX-KT antennas.
Note
The ML-2452-APA2-02 and AH-ACC-ANT-AX-KT antennas must be purchased separately.
20 ExtremeWireless™ AP305C/CX Access Points
AP305C (maxinum antenna
gain)
2.7 dBi
4.0 dBi
AP305CX (maximum antenna
gain)
3.0 dBi
5.0 dBi
