Check entire box and all packing materials for parts. Before beginning assembly, read the
instructions and identify parts using the fi gures and parts listed in this document.
It is critical that all parts be carefully inspected prior to installation. If any damage occurred in
transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit.
Proper installation cannot be overstressed, as an improper installation voids Aqua Creek's
warranty and may aff ect the safety of the user.
Copyright © 2021 Aqua Creek Products All Rights Reserved
400 LB. [181 kg] MAXIMUM WEIGHT CAPACITY
LEAVE THIS MANUAL WITH LIFT OWNER
Lift safety can only be ensured if the lift is installed and
Lift safety can only be ensured if the lift is installed and
operated according to these instructions.
•
• NEVER permit children to play on or around the lift
•
• Do not allow children to use the lift without adult
supervision
•
• NEVER apply direct water pressure to the electronics
•
• NEVER use the lift with a dry pool
READ CAREFULLY
Power EZ 2
Manual
PART #: F-PEZPL2-04
MANDATORY
Read and follow all instructions.
1
Revised 5/28/21
Advertisement
Table of Contents
Related Manuals for Aqua Creek Products Power EZ 2
Summary of Contents for Aqua Creek Products Power EZ 2
- Page 1 It is critical that all parts be carefully inspected prior to installation. If any damage occurred in transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit. Proper installation cannot be overstressed, as an improper installation voids Aqua Creek’s warranty and may aff...
-
Page 2: Page Description
Power EZ 2 Components The Power EZ 2 lift will arrive partially assembled in multiple boxes. Begin by removing all parts from the boxes and locating the parts for your lift in the parts lists below. Refer to the parts breakdown drawings in the back of this manual for assistance. - Page 3 Clean out the hole using a vacuum or compressed air. Check that the hole is deep enough to allow the anchor to be flush with the finished deck surface. Ground the anchor according to your local code requirements. This may require additional drilling and/or other tools. Copyright © 2021 Aqua Creek Products All Rights Reserved Revised 5/28/21...
- Page 4 [30.5 cm] 12" MIN [51 cm] 20" MAX ANCHOR SOCKET [15 cm] TOP OF SLAB 6" MIN [20.3cm] 8" MIN. 42" CEMENT/EPOXY 48" GROUNDING LUG FIGURE 1 Copyright © 2021 Aqua Creek Products All Rights Reserved Revised 5/28/21...
-
Page 5: Anchor Installation: New Construction
Verify all the measurements for accuracy and pour the deck as you normally would, making sure not to get any concrete inside the anchor system. Allow the concrete to cure before installing and using the lift. Copyright © 2021 Aqua Creek Products All Rights Reserved Revised 5/28/21... - Page 6 CONTROL BOX 9/16” WRENCH (2) 5/32” HEX KEY AND BRACKET The Power EZ 2 Pool Lift arrives with the boom arm attached to the mast. To complete the assembly, layout all STEP 1 parts on a large, clean area. STEP 1. Attach the control box to the lifts mast using the supplied #10 socket head screws and a 5/32”...
- Page 7 For any person operating the lift, please continue to operating instructions. EZ TURN Read carefully for comprehension. Copyright © 2021 Aqua Creek Products All Rights Reserved Revised 5/28/21...
- Page 8 The Power EZ 2 Pool Lift requires the use of an operator to assist the lift occupant with the transfer into the pool. There are two methods of loading the lift occupant into the harness. The method of loading will depend on the physical ability of the lift occupant.
-
Page 9: Basic Troubleshooting
Note: the lift will not retract if the battery is not fully charged or if the control box is not working. The emergency button only overrides the remote handset. Copyright © 2021 Aqua Creek Products All Rights Reserved Revised 5/28/21... -
Page 10: Proper Care Of Pool & Spa Lifts
3M Scotch Brite™ pad. Use white epoxy paint to touch up the finish. Apply wax to protect when dry. For service and/or replacement parts, contact Aqua Creek Products Toll free: (888) 687-3552 Copyright © 2021 Aqua Creek Products All Rights Reserved... -
Page 11: Parts List
BOLT, 316 SS, 1/4-20 X 1/2 BHSCS HB00-U017 REMOTE, LINAK, 2 BUTTON F-044CH CHARGER, FOR 24V LINAK BATTERY ZIP TIE, 6” 6” CABLE ZIP TIE (NOT PICTURED) *Not pictured above Copyright © 2021 Aqua Creek Products All Rights Reserved Revised 5/28/21... - Page 12 SHALL AQUA CREEK’S LIABILITY EXCEED THE ENTIRE AMOUNT PAID TO AQUA CREEK BY THE ORIGINAL PURCHASER FOR THE FAILED OR DEFECTIVE PRODUCT. IN NO EVENT SHALL AQUA CREEK PRODUCTS, LLC BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL, INDIRECT, PUNITIVE OR EXEMPLARY DAMAGES OR LOST PROFITS FROM ANY BREACH OF THIS LIMITED WARRANTY OR OTHERWISE.
- Page 13 Immedia ately remove e from servic ce any lift th hat does not have 100% compliance with the ins spection until the appropriate e corrections s have been made by a q qualified pe rson. Page 1 of 4 4 Copyright © 2021 Aqua Creek Products All Rights Reserved Revised 5/28/21...
- Page 14 . . Inspect li ift slings, sea at belts, and other simila ar stitched a and webbed or weaved materials s for damage e, fatigue, an nd/or deteri ioration. Re place at first t sign of any y fatigue o or damage. TES/RECOMM MENDATION NS: 4 Page 2 of 4 Copyright © 2021 Aqua Creek Products All Rights Reserved Revised 5/28/21 ...
- Page 15 Once the e battery is f ully charged d up to 24 to o 28 volts, cy ycle the lift (u up, down, rotate) co ounting the cycles. If th he battery is in good con ndition, the l ift should easily co mplete at le ast 15 cycle s without a load. TES/RECOMM MENDATION NS: 4 Page 3 of 4 Copyright © 2021 Aqua Creek Products All Rights Reserved Revised 5/28/21 ...
- Page 16 pool with hout hitting anything lik e a wall, rail , bench, etc .. c. Rotate lif ft at least 90 0 degrees ov ver the wate r and back a again if appli cable TES/RECOMM MENDATION NS Page 4 of 4 4 Copyright © 2021 Aqua Creek Products All Rights Reserved Revised 5/28/21 ...
