Page 3: Table Of Contents
4.1 General list and sequence of functions 5. Service and maintenance 6. Generator operation mode 7. Storage regulations 8. Transportation 9. Scope of delivery 10. Safety instructions 11. Warranty obligations 12. ACCEPTANCE CERTIFICATE PATON Feeder DC MIG/MAG - 2 -... -
Page 4: General Information
Everything is set by default to optimum parameters. The unit is highly optimized to work with PATON sources and will require minimal time for user adaptation, as the mating spots for connectors and installation are already provided in the design. - Page 5 14 – Wire feeder fuses; 15 – Wire coil holder with spring braking mechanism; 16 – Safety gas supply connector; 17 – Control signal connector from wire feeder to external welding power source. PATON Feeder DC MIG/MAG - 4 -...
-
Page 6: Commissioning
2.4 CONNECTING THE POWER CONTACT This is carried out by the power bayonet connector 8 to the corresponding pole of the external welding source. As a rule, it is connected to the "positive" pole for solid PATON Feeder DC MIG/MAG - 5 -... -
Page 7: Connecting The Power Source Control Plug
Look for it in the power supply manual. The new generation of PATON power supply sources already includes all the features, so the adaptation will be done with minimum effort. It is enough to check the presence of the control connector on the rear panel of the source. -
Page 8: Installation Of The Wire Coil
The wire feed speed will increase smoothly to the maximum for convenience. This can be seen by the display on the front panel. PATON Feeder DC MIG/MAG - 7 -... -
Page 9: Operation Of The Wire Feeder
By default, the safety gas pre-purge is set to 0.5 sec, post-purge to 1.5 sec. 3.1 WELDING PROCESS CYCLE - MIG/MAG - 2T To change the value of any function, see step 4. PATON Feeder DC MIG/MAG - 8 -... -
Page 10: Torch Button Function - 2T
[t.uP] is activated, as well as additional functions (e.g. additional functions (for example, the last generation digital PATON sources have a pulse mode), all according to the welding process cycle shown in the cyclogram of 3.1. -
Page 11: Torch Button Function - 4T And
[t.uP], as well as additional functions (for example, the last generation of PATON digital sources have a pulse mode) are executed. All this is according to the welding process cycle shown in the cyclogram of cl. -
Page 12: Service And Maintenance
Wire feeder unit – 1 pc; Pneumatic quick connector – 1 pc; Operation manual – 1 pc. PATON branded corrugated box – 1 pc; For Feeder-15-2 model: ABICOR BINZEL semi-automatic torch – 1 pc; Rollers for solid wire 0,6-0,8; 1,0-1,2 –... -
Page 13: Safety Instructions
- Remove any smoke and harmful gases from the workspace using special means; - Ensure an adequate supply of fresh air; - Solvent vapors must not enter the radiation zone of the welding arc. PATON Feeder DC MIG/MAG - 12 -... -
Page 14: Warranty Obligations
Check the unit for external damage at least once a week. 11. WARRANTY OBLIGATIONS PATON INTERNATIONAL warrants that the wire feeder will operate properly if the user follows the operating, storage and transportation conditions. WARNING! There is no free warranty service if the welding machine is mechanically... - Page 15 - In the absence of correct or any filling of the certificate by the seller when selling the machine, - The warranty period is extended for the period of warranty service in the service center. PATON Feeder DC MIG/MAG - 14 -...
-
Page 16: Acceptance Certificate
12. ACCEPTANCE CERTIFICATE PATON Feeder-15-2/15-4 inverter feeding unit Serial number _______________BP, recognized as serviceable. Sale date ”_____”________________20____. Seal here. _____________________ (seller's signature) ================================================================== PATON Feeder DC MIG/MAG - 15 -... - Page 17 Cause: ___________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ================================================================ Date of acceptance for repair ”_____”_________________20____г. __________________ (signature) Signs of inoperability: ____________________________________________________________________ Date of acceptance for repair ”_____”_________________20____г. __________________ (signature) Signs of inoperability: ____________________________________________________________________ Cause: ___________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ PATON Feeder DC MIG/MAG - 16 -...
- Page 18 Date of acceptance for repair ”_____”_________________20____г. __________________ (signature) Signs of inoperability: ____________________________________________________________________ Cause: ___________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ================================================================ Date of acceptance for repair ”_____”_________________20____г. __________________ (signature) Signs of inoperability: ____________________________________________________________________ Cause: ___________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ PATON Feeder DC MIG/MAG - 17 -...
