Page 2: Table Of Contents
SPECIFICATION DATA ..................DELIVERY SET ....................TROUBLESHOOTING ..................SAFETY INSTRUCTIONS .................. ELECTRICAL SCHEMATIC DIAGRAM ............WARRANTY ......................WASTE ELECTRICAL & ELECTRONIC EQUIPMENT ........ACCEPTANCE CERTIFICATE ................WARRANTY CARD .................... 1 | P a g e ® PATON VDI SERIES MINI DC MMA... - Page 3 INVERTER RECTIFIER PRODUCT: PATON VDI – 150 MINI DC MMA The statement is based on a single evaluation of one sample of above mentioned products. It does not imply an assessment of the whole production. The manufacturer should ensure that all product in series production are in conformity with the product sample detailed in this report.
-
Page 4: General Information
® The basic advantages of the PATON welding unit are the following: The welding unit is protected against long-time fluctuations of power supply voltage and ensures welding arc stabilization when the input voltage of the unit changes in the range of 170 V through 260 V. -
Page 5: Technical Characteristics
(m) cable conductor (mm KG 1 8 1 – 4 KG 1 10 2 – 5 VDI MINI KG 1 16 3 – 8 4 | P a g e ® PATON VDI SERIES MINI DC MMA... -
Page 6: Controls And Connectors
1.2. CONTROLS AND CONNECTORS 5 | P a g e ® PATON VDI SERIES MINI DC MMA... -
Page 7: Setting The Welding Unit Into Operation
When operating the welding unit in cold season, after the unit was switched off and cooled, condensate may appear inside the unit, so switch on the welding unit only 3 – 4 hours after the switching off!!! 6 | P a g e ® PATON VDI SERIES MINI DC MMA... -
Page 8: Connection To A Power Supply System
4. Connect the power cable of the welding unit to the outlet of the power supply system; 5. Set switch 3 to position 1 (switching on). 6. The device is ready for use. Enjoy Your work. 7 | P a g e ® PATON VDI SERIES MINI DC MMA... -
Page 9: Increased-Current Arc Starting Hot-Start
The set welding current is 90 A. The current at the increased-current arc starting stage is 90A + 33% = 120 A. t (s) Figure 1. Increased-current arc starting HOT-START 8 | P a g e ® PATON VDI SERIES MINI DC MMA... -
Page 10: Reduced Welding Voltage Function Arc-Force
After the completion of works with the welding unit, apply to the unit a plate with a warning text prohibiting switching on the unit. 9 | P a g e ® PATON VDI SERIES MINI DC MMA... -
Page 11: Operation With An Electric Generator
In this case, the electrical outlet of the power supply system and the power cable of the welding unit should be selected with consideration for the actual power supply voltage. 10 | P a g e ® PATON VDI SERIES MINI DC MMA... -
Page 12: Delivery Set
2. The welding cable 3 m in length with electrode holder – 1 pcs; 3. The welding cable 2 m in length with grounding clamp – 1 pcs; 4. Shoulder-carry belt ® 5. Plastic case „PATON ” – 1 pcs; – 1 pcs. 6. Operation manual 10. TROUBLESHOOTING... -
Page 13: Safety Instructions
Protective clothing should not restrain movements. If possible, it should not be made of synthetic materials. Electrocution can be fatal !!! 12 | P a g e ® PATON VDI SERIES MINI DC MMA... - Page 14 Do not perform any maintenance work on the unit. Removing the outside cover of the device while it is connected to the network and using the device with the lid removed is forbidden. 13 | P a g e ® PATON VDI SERIES MINI DC MMA...
- Page 15 SAFETY MARK: This device is suitable for mains power, for welding work in an environment of higher standard of electric shock. It is recommended that the power line be provided with a separate protection against the shock absorber. 14 | P a g e ® PATON VDI SERIES MINI DC MMA...
-
Page 16: Electrical Schematic Diagram
12. ELECTRICAL SCHEMATIC DIAGRAM BPK-0400 15 | P a g e ® PATON VDI SERIES MINI DC MMA... -
Page 17: Warranty
13. WARRANTY The Pilot Plant of Welding Equipment of the E.O Paton Electric Welding Institute guarantees the correct operation of the power supply if the costumers provided service conditions, storage and transportation. ATTENTION!!! Warranty commitments are canceled in case of mechanical damage! Basic warranty for MINI welding rectifiers is granted for a period of 3 years. -
Page 18: Waste Electrical & Electronic Equipment
All rights reserved. This document is protected by copyright. Copying or distributing the User Manual in whole or in excerpts without MasterWeld permission is prohibited 17 | P a g e ® PATON VDI SERIES MINI DC MMA... -
Page 19: Acceptance Certificate
ATTENTION The delivery of the device to the Paton Service Center is carried out at the expense of the manufacturer for the entire warranty period from the date of purchase exclusively in Poland! 18 | P a g e ®... -
Page 20: Warranty Card
(Signature) (Signature) FAULTS DETECTED AND FAULTY-CONDITION CAUSE: ======================================================================= Tel. Technical support: +48 22 290 86 96 Address of the service center: 35105, Poland, Rzeszów, 14 Przemysłowa Street, 19 | P a g e ® PATON VDI SERIES MINI DC MMA... - Page 21 (Signature) (Signature) FAULTS DETECTED AND FAULTY-CONDITION CAUSE: ======================================================================= Tel. Technical support: +48 22 290 86 96 Address of the service center: 35105, Poland, Rzeszów, 14 Przemysłowa Street, 20 | P a g e ® PATON VDI SERIES MINI DC MMA...
