9. Bag Assembly
a. Pull bag cardboard collar down to release
plastic bag dock from connector. Remove
paper bag.
Note: A boss was added to the rear bag dock
to prevent usage of unauthorized bags. A
notch was added to the bag assembly to
allow the bag to be locked into position.
b. Separate bag dock and bag dock rear by
pressing inward on bag dock rear to unhinge.
c. Carefully spread forks on bag dock rear and
work bag dock rear upward and off of bag
duct.
8 |
P a g e
d. Slide bag assembly off unit.
10. Carry Handle
a. Remove screw in carry handle retainer.
b. Spread handle retainer apart and slide it off
of the connector assembly.
c. Remove carry handle – trapped in position
by the handle retainer.
