b. Remove cord clip to access sixth screw and
remove.
c. Lift off handle cover.
d. Remove switch button – snap fit.
e. Disconnect yellow and red lead at terminal
connections in top of handle and slightly
spread handle seat to remove Power PBC.
8. Cord Assembly / Power Cord
a. Remove handle cover – section 7.
b. Locate and remove cord assembly lead
wires at applicable terminals - black at top of
handle and white at midpoint of handle.
7 |
P a g e
c. Feed cord strain relief out of handle to
remove Cord Assembly.
Power Cord
a. Remove lead wires at white and black to
yellow terminals and feed power cord out of
handle.
b. Remove base assembly – section 1.
c. Disconnect power cord connector at PCB.
d. Remove strain relief from main body and
feed power cord out of position.
