1. Base Assembly
a. Remove 7 screws and lift base assembly off
of unit. This requires a T20 torx driver.
b. The base is stocked as an assembly which
includes the components shown below.
Once the base assembly is removed the
internal components can be accessed.
4 |
P a g e
2. Belt / Brushroll
a. Remove edge brush holder to access belt –
2 screws.
Remove belt by sliding it off of the motor
shaft and brushroll pulley.
Brushroll
a. Remove base assembly – section 1.
b. Slide Brushroll out of baseplate.
Upon reassembly position brushroll with
thread guard with no notches upward for
worn brushroll and notches upward for new
brushroll. Both sides must be the same.
