OPERATING MANUAL
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth
defects or other reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry
products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type
of work. To reduce your exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such as those dust masks that
are specially designed to filter out microscopic particles.
Horsepower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.5
Free Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2,600 RPM
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8.7"
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.8 Lbs.
Sound Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86 dBA
Vibration Level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.5 m/s²
Recommended Air Pressure . . . . . . . . . . . . . . . . . . . . . . . .90 PSI
Air Inlet Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/4" NPT
Recommended Hose Size . . . . . . . . . . . . . . . . . . . . . . . . 3/8" I.D.
Average Air Consumption . . . . . . . . . . . . . . . . . . . . . . . . 3.5 CFM
CAT3PST
WARNING INFORMATION
•
WARNING
SPECIFICATIONS
PARTS LIST
•
Copyright © Professional Tool Products, 2022
Pinstripe Removal Kit
WARNING
• MAXIMUM RPM OF 2,600
• MAX. AIR PRESSURE:
90 PSIG, 6.2 BAR
RPM OF THE ACCESSORY
RPM
RPM
RPM
MUST EXCEED TOOL RPM
ALWAYS READ
INSTRUCTIONS BEFORE
USING POWER TOOLS
ALWAYS WEAR
SAFETY GOGGLES
ALWAYS WEAR HEARING
PROTECTION
ALWAYS WEAR FACE
PROTECTION
AVOID PROLONGED
EXPOSURE TO VIBRATION
All rights reserved
CAT3PST
03/21/2022
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cornwell Tools CAT3PST
Summary of Contents for Cornwell Tools CAT3PST
- Page 1 CAT3PST Pinstripe Removal Kit OPERATING MANUAL WARNING INFORMATION PARTS LIST • • WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: WARNING •...
- Page 2 CAT3PST Pinstripe Removal Kit FAILURE TO OBSERVE THESE WARNINGS COULD RESULT IN INJURY • Tool shaft may continue to rotate briefly after throttle is THIS INSTRUCTION MANUAL CONTAINS IMPORTANT released. Avoid direct contact with accessories during and after SAFETY INFORMATION.
-
Page 3: Operation
CAT3PST Pinstripe Removal Kit OPERATION Air Supply Whip Hose Do Not Install Filter Quick Coupling Nipple OPERATION NOTE: Always shut off air supply, drain hose of air Nipple Here pressure and disconnect tool from air supply when not in use, before changing accessories or when making repairs. -
Page 4: Warranty Coverage
CAT3PST Pinstripe Removal Kit WARRANTY COVERAGE Cornwell Quality Tools Company (“Cornwell”) warrants this product against defects in material and workmanship for a period of ONE (1) YEAR from the date of original retail purchase. Subject to the conditions and limitations set forth below, Cornwell will, at its option, either repair or replace any part of the product(s) that proves defective by reason of improper workmanship or materials. -
Page 5: Parts List
CAT3PST Pinstripe Removal Kit PARTS LIST Item Part No Parts Name Item Part No Parts Name RS103001 REGULATOR SET RS601018 BEARING (608ZZ) RS288304 SNAP RING RS31525 WASHER RS103002 VALVE STEM SET RS601020 BEARING (6001Z) RS31509 AIR INLET RS601008 RING GEAR LINK...
