Operating Instructions • Warning Information
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth
defects or other reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry
products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type
of work. To reduce your exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such as those dust masks that
are specially designed to filter out microscopic particles.
SPECIFICATIONS
Free Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14,000 RPM
Horsepower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.0
Wheel Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4"
Air Inlet Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/4" NPT
Recommended Hose Size . . . . . . . . . . . . . . . . . . . . . . . . 3/8" I.D.
Maximum Air Pressure . . . . . . . . . . . . . . . . . . . 90 psig, 6.2 bar
Average Air Consumption . . . . . . . . . . . . . . . . . . . . . . . . 4.1 CFM
Overall Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13.6"
Vibration Level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.3 m/sec²
Sound Pressure Level . . . . . . . . . . . . . . . . . . . . . . . . . . . 87 dBA
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.2 Lbs.
CAT851XLR
• Parts Breakdown
WARNING
• MAXIMUM RPM OF 14,000
• MAX. AIR PRESSURE:
90 PSIG, 6.2 BAR
ALWAYS READ
INSTRUCTIONS BEFORE
USING POWER TOOLS
ALWAYS WEAR
SAFETY GOGGLES
ALWAYS WEAR HEARING
PROTECTION
ALWAYS WEAR FACE
PROTECTION
ALWAYS WEAR HAND
PROTECTION
AVOID PROLONGED
EXPOSURE TO VIBRATION
RATED RPM OF THE
ACCESSORY MUST
RPM
RPM
RPM
EXCEED THE MAXIMUM
TOOL RPM SHOWN
CAT851XLR
Blue Power
®
Extended Cut-Off Tool
Copyright © Professional Tool Products, 2018
1.0 HP
All rights reserved
rev 04/25/18
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cornwell Tools blue POWER CAT851XLR
Summary of Contents for Cornwell Tools blue POWER CAT851XLR
- Page 1 Operating Instructions • Warning Information • Parts Breakdown WARNING • MAXIMUM RPM OF 14,000 • MAX. AIR PRESSURE: WARNING 90 PSIG, 6.2 BAR ALWAYS READ Some dust created by power sanding, sawing, grinding, drilling, and other INSTRUCTIONS BEFORE construction activities contains chemicals known to cause cancer, birth USING POWER TOOLS defects or other reproductive harm.
- Page 2 • Use accessories rated at 14,000 RPM or more. • Al ways op er ate, in spect and main tain this tool in • Use accessories recommended by Cornwell Tools. ac cor dance with Amer i can Na tion al Stan dards •...
- Page 3 PARTS BREAKDOWN - CAT851XLR REF. # ITEM # DESCRIPTION REF. # ITEM # DESCRIPTION RS15401 Regulator RS2943936 Angle Housing RS288302 O-Ring (P10) RS288331 Grease Fitting (3/16") RS288303 O-Ring (P9) RS25480 Snap Ring RS288304 Snap Ring (ISTW12) RS2943939 RS246002 O-Ring (3.5x1.4) RS2943940 Spring RS488306...
- Page 4 When finished cutting, lift off the work before stopping the motor. Air Supply Al ways use the required wheel guard to prevent injury from broken Whip Hose Do Not Install Filter cut-off wheel parts. If a guard has withstood a wheel breakage, Quick Coupling Nipple Nipple...
