Long barrel air hammer

Advertisement

OPERATING MANUAL
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth
defects or other reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry
products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type
of work. To reduce your exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such as those dust masks that
are specially designed to filter out microscopic particles.
Blows per minute . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2,500 BPM
Stroke Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3/4"
Shank Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.401"
Bore Diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/4"
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11.2"
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.2 Lbs.
Maximum Air Pressure . . . . . . . . . . . . . . . . . . . 90 psig, 6.2 bar
Air Inlet Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/4" - 18 NPT
Recommended Hose Size . . . . . . . . . . . . . . . . . . . . . . . . 3/8" I.D.
Average Air Consumption . . . . . . . . . . . . . . . . . . . . . . . 5.75 CFM
CAT5250AHB
WARNING INFORMATION
WARNING
SPECIFICATIONS
bluePOWER
PARTS LIST
CAT5250AHB
®
Long Barrel Air Hammer
WARNING
• MAX. AIR PRESSURE:
90 PSIG, 6.2 BAR
ALWAYS READ
INSTRUCTIONS BEFORE
USING POWER TOOLS
ALWAYS WEAR
SAFETY GOGGLES
ALWAYS WEAR HEARING
PROTECTION
AVOID PROLONGED
EXPOSURE TO VIBRATION
Copyright © 2023
All rights reserved
06/27/2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the bluePOWER CAT5250AHB and is the answer not in the manual?

Questions and answers

Summary of Contents for Cornwell Tools bluePOWER CAT5250AHB

  • Page 1 CAT5250AHB bluePOWER ® Long Barrel Air Hammer OPERATING MANUAL WARNING INFORMATION PARTS LIST • • WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: •...
