Do NoT overloaD. overloaDiNg caN
cause Damage To, or failure of The
sTaND.
This sTaND is DesigNeD for use oNly oN
harD level surfaces capable of sup­
porTiNg The loaD. use oN oTher ThaN
harD level surfaces caN resulT iN
sTaND iNsTabiliTy aND TippiNg of loaD.
lock The mouNTiNg­plaTe roTaTiNg
mechaNism before applyiNg a loaD.
release roTaTioNal lockiNg Device
sloW­ly aND carefully.
alW­ays use high sTreNgTh sae graDe 8
bolTs for eNgiNe mouNTiNg bolTs.
make sure W­iDesT seT of mouNTiNg heaD
fiNgers are NearesT The grouND W­heN
mouNTiNg aN eNgiNe To The sTaND.
alW­ays be sure ThaT The loaD is
ceNTereD aND secureD To The mouNTiNg
plaTe. off­ceNTer loaDs may make The
loaD aND haNDle roTaTe iN eiTher
DirecTioN W­heN The roTaTioNal lockiNg
Device is releaseD.
Never looseN mouNTiNg bolTs uNless
eNgiNe is supporTeD by a craNe or
hoisT.
Do NoT use sTaND To Dolly or TraNsporT
eNgiNes.
No alTeraTioNs To The sTaND or aDapTers
shall be maDe.
Do NoT roTaTe moTor uNless rear legs
are secureD from TippiNg.
reaD, sTuDy aND uNDersTaND all
iNsTrucTioNs before operaTiNg.
failure To heeD These W­arNiNgs may
resulT iN loss of loaD, Damage To
sTaNDs, aND/or failure resulTiNg iN
properTy Damage, persoNal or faTal
iNJury.
CSE-1000
This operaTing
manual conTains
imporTanT safeTy
informaTion.
read carefully
and undersTand
all informaTion
before operaTing
This Tool.
save This manual
for fuTure use.
do noT crawl under engine or place any parT
of your body under engine aT any Time during
mounTing of engine, use of sTand, or removal
of engine.
refer To engine service manual for correcT
lifTing poinTs, mounTing poinTs and mounTing
bolTs! mounTing bolTs should be Torqued aT
appropriaTe amounT To mainTain load.
1
Meets or exceeds ASME PALD-1997
standards for performance & safety.
CSE-1000
1000 Lb.
Geared
Engine Stand
Rev. 07/24/07
