OPERATING MANUAL
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth
defects or other reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry
products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type
of work. To reduce your exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such as those dust masks that
are specially designed to filter out microscopic particles.
Tool Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.75"
Tool Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4.50"
Tool Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7.88"
Tool Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.7 lb
Maximum Free Speed . . . . . . . . . . . . . . . . . . . . . . . . . 9700 RPM
Maximum Torque/Applied . . . . . . . . . . . . . . . . . . . . . . . 500 ft-lbs
Breakaway Torque. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 650 ft-lbs
Sound Pressure Level . . . . . . . . . . . . . . . . . . . . . . . . . . 97.5 dBA
Vibration Level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9.27 m/s²
Air Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4.7 cfm
Recommended Hose Size . . . . . . . . . . . . . . . . . . . . . . . . . 3/8" ID
Air Inlet Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/4" NPT
CAT4212A / CAT4212GA
1/2" bluePOWER
WARNING INFORMATION
•
WARNING
SPECIFICATIONS
-Save these instructions-
1/2" bluePOWER
®
®
STUBBY IMPACT WRENCH - GREEN
•
1
CAT4212A / CAT4212GA
STUBBY IMPACT WRENCH
WARNING
ALWAYS READ
INSTRUCTIONS
BEFORE USING
POWER TOOLS
ALWAYS WEAR
SAFETY GOGGLES
ALWAYS WEAR
HEARING
PROTECTION
AVOID PROLONGED
EXPOSURE TO
VIBRATION
Copyright © Professional Tool Products, 2021
All rights reserved
05/10/2021
Advertisement
Table of Contents
Related Manuals for Cornwell Tools bluePOWER CAT4212A
Summary of Contents for Cornwell Tools bluePOWER CAT4212A
- Page 1 CAT4212A / CAT4212GA 1/2" bluePOWER ® STUBBY IMPACT WRENCH 1/2" bluePOWER ® STUBBY IMPACT WRENCH - GREEN OPERATING MANUAL WARNING INFORMATION PARTS LIST • • WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to cause cancer, birth defects or other reproductive harm.
- Page 2 Use hear ing pro tec tion as rec om mend ed by your em ploy er or OSHA reg u la tion. • Use accessories recommended by Cornwell Tools. • Keep the tool in ef fi cient op er at ing con di tion.
- Page 3 CAT4212A / CAT4212GA 1/2" bluePOWER ® STUBBY IMPACT WRENCH 1/2" bluePOWER ® STUBBY IMPACT WRENCH - GREEN OPERATION Air Supply Whip Hose Do Not Install Filter Quick Coupling Nipple Nipple This tool is an impacting tool and not a torque meter. When specific Here torque is required, it must be checked with a torque meter after fitting the fastener with the impact.
- Page 4 CAT4212A / CAT4212GA 1/2" bluePOWER ® STUBBY IMPACT WRENCH 1/2" bluePOWER ® STUBBY IMPACT WRENCH - GREEN WARRANTY COVERAGE Cornwell Quality Tools Company (“Cornwell”) warrants this product against defects in material and workmanship for a period of TWO (2) YEARS from the date of original retail purchase.
- Page 5 CAT4212A / CAT4212GA 1/2" bluePOWER ® STUBBY IMPACT WRENCH 1/2" bluePOWER ® STUBBY IMPACT WRENCH - GREEN PARTS LIST Item Part No Parts Description Item Part No Parts Description RS223801 HAMMER CASE ASS'Y (incl. 102&109) * RS223826 C-RING (RTW #16) RS223802 ANVIL BUSHING STEM SEAL...
