Winchester - Coffee Table
Assembly Instructions -
Dimensions
Width - 99.6cm
Depth - 49.5cm
Height - 46.6cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please visit www.argos-support.co.uk
or email: Help@ClickSpares.co.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928.
For any other queries please contact the Customer Helpline on: 0345 640 2020
Please keep for future reference
408/5571
MADE IN
BRITAIN
Issue 1 - 15/07/15
Advertisement
Related Manuals for Argos Winchester 408/5571
Summary of Contents for Argos Winchester 408/5571
- Page 1 Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928.
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 29kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 Components - Panels If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020...
- Page 4 Components - Fittings If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly.
- Page 5 Assembly Instructions Step 1 Prepare the 2 drawer fronts Screw 2 metal dowels into each of the drawer fronts Note: Tighten the metal dowels up fully against the panels. Step 2 Prepare the drawer sides Insert a small locking into the hole shown on the left drawer side and the right...
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 8 Prepare the left side Place a runner the left side shown. Slide back the Finished top of runner and use the front edge 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into...
- Page 8 Assembly Instructions Step 9 Prepare the right side Place a runner the right side shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Finished Slide the runner front edge back the other way and fit the 2nd screw into...
- Page 9 Assembly Instructions Step 10 Prepare the shelf Screw 2 metal dowels into the shelf Insert 4 large locking nuts into the shelf . . Tap 4 wooden dowels into the shelf . . Step 11 Fit the shelf Push the shelf onto the right side Use a screwdriver to...
- Page 10 Assembly Instructions Step 12 Prepare the divider Place a runner the divider as shown. Slide back the top of runner and use the 2nd Note: Due to the manufacturing hole from the front to fit process, the 2 holes for the the 1st screw large locking nut can be on either surface of the divider.
- Page 11 Assembly Instructions Step 14 Prepare 1 back Tap 2 wooden dowels into a back . . Step 15 Fit the back Push the back onto the right side Note: Support the back until it is secured in the next step. Step 16 Secure the back Gently tap 2 long wooden...
- Page 12 Assembly Instructions Step 18 Prepare the 4 rails Insert 2 large locking nuts into each of the rails Tap 2 wooden dowels Finished into each of the rails front edge Step 19 Fit the back Push the back onto the divider Note: Support the back until the left side has been fitted.
- Page 13 Assembly Instructions Step 15 Fit the left side Push the left side onto the assembly. Use a screwdriver to tighten the 6 large locking nuts fitted to the shelf and the 4 rails Step 18 Prepare the top Screw 4 metal dowels into the top Step 18 Polystyrene...
- Page 14 Assembly Instructions Step 24 Finished Prepare the 2 side top edge plinths Insert 2 large locking nuts into each of the 2 side plinths Tap 2 wooden dowels into each of the 2 side plinths Step 25 Prepare the 2 front plinths Profiled Screw 2 metal dowels...
- Page 15 Assembly Instructions Step 27 Fit the plinths Position the 4 plinths over the assembly ensuring that the bottom edge of the plinths are flush with the bottom edge of the sides, as shown. Secure the 2 side plinths through the left end .
- Page 16 Assembly is complete If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928.
