STEINEL Multisensor True Presence IP Manual page 59

11. Technical specifications
– Dimensions (H × W× D):
– Power supply:
– Mounting height:
– Angle of coverage:
– Max. reach:
– Ambient temperature:
– IP rating:
– Bluetooth frequency:
– Bluetooth transmission power:
– UWB transmission power:
– True Presence frequency:
Sensor values:
– Light measurement:
– Temperature:
– Relative humidity:
– CO :
2
– VOC:
– Air pressure:
– Noise level:
Concealed (UP): 123 × 123 × 52 mm
Surface-mounted (AP): 142 × 142 × 45 mm
(up to a mounting height of 4 m)
(adjustable with centimetre precision)
(responds to micro-movements
resulting from the vital functions)
– 27 –
standard PoE (IEEE 802.3 af)
Passive PoE (24-55 V) SELV
Ø 9 m True Presence
Ø 15 m presence
Ø 15 m movement
≤ -41 dBm/MHz
400-10,000 ppm
300-1,200 mbar
2.8 - 12 m
360°
0°C to +50°C
IP20
2.4-2.48 GHz
4 dBm/2.5 mW
7.2 GHz
2-2,000 lux
0-40°C
0-100%
0-1,000 ppm
0-120 dB
