STEINEL Multisensor True Presence IP Manual page 54

Setting True Presence IP detection
• Setting reach via:
– Web interface
– IP interface
– App
First time of using True Presence
During initial commissioning, the presence detector creates
a room image.
The room must be free of movement for 2 to 2.5 minutes
for this.
The process is completed when the blue LED goes out.
Setting True Presence detection
The reach can be set via the mounting height, radius and
scenario parameters.
Scenario 9:
Small office, quiet workplace
This scenario features maximum sensitivity. To prevent
undesired switching, it should be used for small areas.
Scenario 8:
Large office, quiet workplace
As per scenario 9, but with a slightly reduced sensitivity.
Also suitable for large areas.
Scenario 7:
Large office, large entrance area
As scenario 8, but with a further reduced sensitivity.
Scenario 6:
Hotel room, room with persons sleeping
This scenario also provides maximum sensitivity. In
addition, signal processing has been optimised to reliably
detect the presence of persons sleeping.
