Note: Though these modems are capable of 56 Kbps download performance, line impairments,
public telephone infrastructure flaws, and other external technological factors currently prevent
connections from reaching this maximum 56 Kbps speed.
Modems on the ISI Card are 'Plug and Play' capable with interactive automatic dialing and command mode
configuration. In standard mode, you can store up to three command lines or telephone numbers of up to 40
characters each in the modems' nonvolatile memory. The modems can dial using pulses or tones and can
recognize dial tones and busy signals for reliable call-progress detection. The modems can detect AT&T calling
card tones. They also have DTR dialing, remote configuration, and 11-bit capabilities, and they incorporate self-
resetting lightning protection. Serial port speeds can be set as high as 230,400 bps. They are both FCC
registered for connection without notification to the telephone company.
The ISI Card has full-duplex intelligent modems with V.42 error correction, V.42bis, and V.44 data compression. The
ISI modems support "Super G3" ITU-T V.34 fax communications at speeds up to 33.6 Kbps with Class 2.1 fax
commands. The ISI modems also support voice functionality (+V commands).

ISI Reset Utility

Multi-Tech's ISI Reset Utility is shipped with each ISI Card. It allows you to reset the modems associated with the
ISI Card in a computer running Windows 2000 Professional, Windows 2000 Server, Windows 2000 Advanced
Server, Windows 2003, Windows XP, Windows Vista, or Windows Server 2008.

Technical Specifications

Computer requirements
Dimensions:
Baud Rates:
Bus Type:
Connectors:
Cables:
Temperature:
Approvals
Power:
Interrupt Request (IRQ):
Warranty:
Manufactured in Mounds View, MN, U.S.A.
MultiModem ISI Server Cards User Guide
Downloaded from Elcodis.com electronic components distributor
Microsoft Windows 2003, Windows XP, Windows 2000 Professional, Windows 2000
Server and Advanced Server, Windows Vista, Windows 2008, Windows 7 or Linux
(kernel 2.4.x).
CD-ROM drive
2 MB of hard disk space
13.25" x 4.2" / 33.66 cm x 10.67 cm
300 bps to 230 Kbps per port
ISI9234 models are PCI Express form factor 1x, PCIe 1.0 compatible.
ISI5634 models are UPCI is PCI spec version 2.1 compatible.
one RJ-45 jack (female) on ISI-4; two RJ-45 jacks (female) on ISI-8
The ISI-8 is shipped with two four-port fan-out cables. Each cable has an RJ-45
plug (male) at one end and four RJ-11 plugs (male) at the other end.
The ISI-4 is shipped with one such four-port fan-out cable.
32° to 149° F (0° to 65° C)
CE Mark
R&TTE
EMC: FCC Part 15; EN55022; EN55024
Safety: UL60950-1; IEC60950-1; AS/NZS 60950-1
250 milliamps @ +5vDC (8 ports; ISI5634UPCI-8)
1.75A @3.3v DC (8 ports; ISI5634UPCI-8)
130 milliamps @ +5v DC (4 ports; ISI5634UPCI-4)
885 milliamps @ 3.3v DC (4 ports; ISI5634UPCI-4)
700 milliamps @ 3.3v DC (4 ports; ISI9234PCIE-4)
1.20A @3.3v DC (8 ports; ISI9234PCIE-8)
One IRQ per card (can be shared)
Two years
