Summary of Contents for Regulus PS K+
- Page 1 Installation and Operation Manual THERMAL STORES PS 400 K+, PS 500 K+, PS 600 K+, PS 700 K+, PS 900 K+, PS 1100 K+ PS K+...
- Page 2 CONTENTS 1 Description ..............................1.1 Models ............................... 1.2 Tank Protection ..........................1.3 Thermal Insulation ..........................1.4 Connection points on the tank ......................1.5 Packaging............................2 General Information ............................3 Dimensions and Other Technical Data ......................4 Operation................................ 5 Typical Layout Examples with Thermal Store .................... 6 Installation and Commissioning ........................
- Page 3 3 - Dimensions and Other Technical Data 400 K+ 500 K+ 600 K+ 700 K+ 900 K+ 1100 K+ pos. connections height [mm] Heat sources G6/4" F 1365 1375 1385 1395 1415 1435 G6/4" F Heating system G6/4" F 1665 1685 1705 1725...
- Page 4 4 - Operation In a thermal store, heating water can be heated up by various types of hot-water boilers, renewable energy sources (heat pumps, solar collectors), or possibly also by electric heating elements. The thermal store is connected to the energy source using a G 6/4“ connection fitting. Should the tank be connected to a solar thermal system, a heat exchanger shall be used for the connection because heating water is not used as the heat transfer fluid in a solar thermal system.
- Page 5 Example II. Biomass boiler (fireplace insert/stove) and electric heating element. │...
- Page 6 6 - Installation and Commissioning Installation shall meet valid rules and may be done by qualified staff only. Defects caused by improper installation, use or handling are not covered by warranty. After the tank is installed and connected to an existing heating system, it is recommended to clean the entire heatingsystem using a suitable cleaning agent, e.g.
- Page 7 Warranty on insulation The insulation is covered by a 24-month warranty. This period starts the next day after the insulation is sold. □ Warranty shall become null and void if: ○ the procedure described in the Installation Manual was not respected, ○...
- Page 8 This product is covered by warranty according to the conditions described in this Manual and according to the Warranty Certificate. A Warranty Certificate is an integral part of the supply.. v1.3-11/2022 ©2022 We reserve the right to errors, changes and improvements without prior notice. REGULUS spol. s r.o. E-mail: sales@regulus.eu Web: www.regulus.eu...
