- Page 1 Installation and Operation Instructions THERMAL STORES with stainless-steel DHW tube heat exchanger HSK 600 PV, HSK 750 PV, HSK1000 PV, HSK 1700 PV HSK PV...
-
Page 2: Table Of Contents
1.2 Tank protection ........................... 1.3 Thermal insulation ..........................1.4 Packaging ............................2 General Information ............................3 Technical Data and Dimensions of HSK PV Model Line ................4 4 Operation ................................ 5 Typical Layout Examples with Thermal Store ..................... 6 Installation and Commissioning ........................ -
Page 3: Description
1 - Description HSK PV Thermal Stores are intended for storing and subsequent distribution of thermal energy of heating water. They are fitted with a stainless-steel tube DHW heat exchanger, permitting installation of electric heating elements and connection of other heat sources. For a better thermal layering, the tank volume is separated by a baffle. -
Page 4: Technical Data And Dimensions Of Hsk Pv Model Line
3 - Technical Data and Dimensions of HSK PV Model Line HSK 600 PV Combination Thermal Store Main features HSK 600 PV Application accumulation of thermal energy for space and DHW heating this combination Thermal Store utilizes a heat pump with PV panels as a heat source for both space and DHW heating;... - Page 5 HSK 600 PV Combination Thermal Store Dimensions TAPPINGS Tipping height without insulation 2050 mm connec- height pos. description tion [mm] Heat sources Incoming from heat source G 6/4“ F 1985 Return to heat source G 6/4“ F 1135 Incoming from heat source G 6/4“...
- Page 6 HSK 750 PV Combination Thermal Store Main features HSK 750 PV Application accumulation of thermal energy for space and DHW heating this combination Thermal Store utilizes a heat pump with PV panels as a heat source for both space and DHW heating; DHW is being prepared in 2 integrated stainless-steel heat exchangers;...
- Page 7 HSK 750 PV Combination Thermal Store Dimensions TAPPINGS Tipping height without insulation 2120 mm connec- height pos. description tion [mm] Heat sources Incoming from heat source G 6/4“ F 1010 Return to heat source G 6/4“ F 1155 Incoming from heat source G 6/4“...
- Page 8 HSK 1000 PV Combination Thermal Store Main features HSK 1000 PV Application accumulation of thermal energy for space and DHW heating this combination Thermal Store utilizes a heat pump with PV panels as a heat source for both space and DHW heating; DHW is being prepared in 2 integrated stainless-steel heat exchangers;...
- Page 9 HSK 1000 PV Combination Thermal Store Dimensions TAPPINGS Tipping height without insulation 2230 mm connec- height pos. description tion [mm] Heat sources Incoming from heat source G 6/4“ F 1205 Return to heat source G 6/4“ F 1200 Incoming from heat source G 6/4“...
- Page 10 HSK 1700 PV Combination Thermal Store Main features HSK 1700 PV Application accumulation of thermal energy for space and DHW heating this combination Thermal Store utilizes a heat pump with PV panels as a heat source for both space and DHW heating; DHW is being prepared in 2 integrated stainless-steel heat exchangers;...
- Page 11 HSK 1700 PV Combination Thermal Store Dimensions TAPPINGS Tipping height without insulation 2350 mm connec- height pos. description tion [mm] Heat sources Incoming from heat source G 6/4“ F 1240 Return to heat source G 6/4“ F 1235 Incoming from heat source G 6/4“...
-
Page 12: Operation
4 - Operation This tank is designed for heating and storing heating water in household or industrial applications, however always in closed pressure circuits with forced circulation. Hot water is heated inside the thermal store from several possible heat sources like various kinds of heating boilers, renewable energy sources or also electric heating elements. A stainless- -steel tube DHW heat exchanger is heated by heating water inside the thermal store. -
Page 13: Installation And Commissioning
6 - Installation and Commissioning Installation must meet valid rules and may be done only by qualified staff. Defects caused by improper installation, use or handling are not covered by warranty. After the tank is installed and connected to an existing heating system, it is recommended to clean the entire heating system using a suitable cleaning agent, e.g. - Page 14 2. Wrap the insulation around the tank carefully. Check that the insulation adheres to its body perfectly. This can be reached by rubbing and patting the insulation by hand from its center evenly in both directions until the insulation adheres to the tank’s surface completely and no bubbles are left. 3.
-
Page 15: Maintenance
8 - Maintenance If the tank is fitted with a heating element, disconnect it from the mains first. Clean the exterior of the tank with a soft cloth and a mild detergent. Never use abrasive cleaners or solvents. Check all connections for leaks. 9 - Disposal Packaging shall be disposed of in compliance with the valid rules. - Page 16 ©2022 We reserve the right to errors, changes and improvements without prior notice. REGULUS spol. s r.o. E-mail: sales@regulus.eu Web: www.regulus.eu...
