 Serial interfaces:
– 1 USB full / low speed device interface
– USART
 On-board resources:
– 3 User defined LEDS
– 10 Pins I/O header (2x5, 0.1" pitch)
 Supports SPI, TWI, and UART
– 1 Buzzer
 On-board RESET button
 On-board HWB button to force AVR into DFU mode at reset
 16 MHz crystal for system clock
The AT88SC19BK3 provided the following features:
 2 SOT23-3 CryptoAuthentication Sockets
– HOST and CLIENT
– Software PWR control
®
 AVR Studio software interface
Notes: 1. AT88Microbase is supported by AVR Studio®, version
higher. For up-to-date information on this and other AVR tool products, please
consult our web site. The newest version of AVR Studio®, AVR tools and this
User Guide can be found in the AVR section of the Atmel web site,
http://www.atmel.com.
2. ATMEL Flip®, In System Programming Version 3.2.2 or higher shall be used for
Device Firmware Upgrade. Please consult Atmel web site to retrieve the latest
version of Flip and the DFU bootloader Hex file if needed
(1)
4.17 (build 666)
or
