Please be sure to visit WWW.Atmel.com/Javan the latest firmware image. Overview This document describes the AT88CK109STK3, which is a development kit for the AT88SA100, AT88SA102, and ATSA8810HS CryptoAuthentication devices. This kit uses a modular approach. development includes...
Page 4
For up-to-date information on this and other AVR tool products, please consult our web site. The newest version of AVR Studio®, AVR tools and this User Guide can be found in the AVR section of the Atmel web site, http://www.atmel.com.
Page 5
Figure 1. AT88CK109STK3 Kit 1.2.1 Device Support AT88CK109BK3 (daughter board) currently supports the following CryptoAuthentication devices: ATSA88100 ATSA88102 ATSA8810HS Locate the latest information about Crypto Authentication at www.atmel.com/Javan Downloaded from Elcodis.com electronic components distributor...
Atmel CryptoAuthentication product assortment 1 USB cable, 6 inches System Requirements The minimum hardware and software requirements are: 200 MB free hard disk space (AVR Studio, FLIP and ATMEL’s Crypto Evaluation Studio) ® Windows XP, X86 processor ...
Section 3 Using the AT88CK109STK3 This chapter describes the features of the AT88Microbase and the AT88CK109BK3 boards. Overview AT88Microbase Components (front side) Figure 2. Hardware JTAG USB Type-A Boot (HWB) TWI / SPI 10-Pin Buzzer Reset Selector Interface Bank switch...
5.0V ( USB ) Default Setting 3.3V 3.3V CryptoCompanion 5.0 ( USB ) Regulator Main board Supply Voltage * Default The CryptoCompanion supply voltage is always 3.3V, regardless of R1and R2 configuration. AT88CK109STK3 User Guide 8699A—CRYPTO—10/09 Downloaded from Elcodis.com electronic components distributor...
Note 1: For the AT88SA100, AT88SA102, and the AT88SA10HS devices, 5.0V is required to burn the fuses. Note 2: The AT88Microbase is shipped with a 16MHz crystal, which allows the AT90USB1287 on-chip USART to obtain the 230.4K baud rate (-3.5% error) required to communicate with a CryptoAuthentication device.
The SPI – TWI selector switch (K1) allows either the SPI pins (MOSI and SCLK) or the TWI pins (SDA and SCL) to be routed to the 10 pin Interface header, J1. See section 3.6.3 for pinout details. TWI – SPI Selector Switch Figure 7. AT88CK109STK3 User Guide 8699A—CRYPTO—10/09 Downloaded from Elcodis.com...
TWI Position SPI Position On-board Resources Description of LED Bank 3.6.1 The AT88Microbase includes 3 general purpose red LEDs, which are connected to PD6, PD5 and PD4. To light an LED, the corresponding port pin must be driven high. To turn off an LED, the corresponding port pin must be driven low.
Page 12
4.0 0.5 Sound Pressure Level: 78dB Description of the Interface Header 3.6.3 The 10-Pin header (J1) of the AT88Microbase provides interfacing for daughter boards. Figure 10. 10-Pin Interface Header 3-10 AT88CK109STK3 User Guide 8699A—CRYPTO—10/09 Downloaded from Elcodis.com electronic components distributor...
Page 13
The AT88Microbase has one CryptoCompanion device (AT88SC108), which is located on the back side of board. The AT88SC018 is designed as the mate to Atmel’s CryptoRF® (CRF) and CryptoMemory® (CM) chips. The SCL and SDA pins are connected to PD0 and PD1, respectively.
AT88Microbase can physically accept a host or a client device in either socket. Therefore, the AT88CK109BK3 can be configured for either a host-client or client- client development. 3-12 AT88CK109STK3 User Guide 8699A—CRYPTO—10/09 Downloaded from Elcodis.com...
Note: When using the demonstration software, the host (AT88SA10HS) and client (AT88SA100 or AT88SA102) devices must be in their respective sockets according to the “HOST” and “CLIENT” texts on the board. HOST and CLIENT Power Configuration The AT88CK109BK3 provides the user with the capability to independently power cycle each socket with software or place the sockets in a constant power-on state, assuming power is applied to the board.
The AT88CK109BK3 maps to the 10-pin header of the AT88Microbase as follow: Table 2. Mapping the AT88CK109BK3 to the AT88Microbase AT88Microbase AT88CK109BK3 Comments Header ( J1 ) Software Power Control HOST Socket 3-14 AT88CK109STK3 User Guide 8699A—CRYPTO—10/09 Downloaded from Elcodis.com electronic components distributor...
Page 17
Not Connected Tied to PB7 with R11 USART (Receive) Software Power Control CLIENT Socket HOST Signal Pin Bit-banging CLIENT Signal Pin Bit-banging / USART (Transmit ) Table 3. Mapping AT88CK109BK3 to the STK500 and STK600 STK500 / STK600 AT88CK109BK3 Comments Tied to Px3 with R11 USART (Receive) CLIENT Signal Pin...
AT90USB1287. This is the easiest and fastest way to reprogram the device directly over the USB interface. The “Flip” PC side application, available for free on Atmel website, offers a flexible and user friendly interface for reprogramming the application over the USB bus.
3.14 3.14.1 Debugging with AVR JTAG ICE mkII Every AT88CK109STK3 can be used for debugging with JTAG ICE MK II. Connect the JTAG ICE mkII as shown in Figure 20, for debugging help; please refer to AVR Studio® Help information.
Thus the on-chip flash bootloader will be erased. It can be restored after the debug session using the bootloader hex file available from ATMEL website. Test Points 3.15...
Section 4 Troubleshooting Guide Table 4. Troubleshooting Guide Problem Reason Solution The blue Power LED is not on. USB Port of AT88Microbase is not Connect AT88Microbase USB port connected to PC. to PC's USB port. The AVR device cannot be The JTAG header is not connected Connect the JTAG header to the programmed.
Section 5 Technical Specifications System Unit ― AT88Microbase o Physical Dimensions L=58 x W=25 x H=12 mm o Weight 9.0g ― AT88CK109BK3 o Physical Dimensions L=74 x W=35 x H=23 mm o Weight 17.5g ― Assembled Module o Physical Dimensions L=100 x W=35 x H=26 mm o Weight 26.5g...
Section 6 Technical Support For technical support, please contact securerf@atmel.com. When emailing or contacting tech support, please do not include any proprietary information you may have input into the device. When requesting technical support, please include the following information: ...
Section 7 Complete Schematic On the next pages, the following documents of the AT88CK109STK3 are shown: AT88Microbase, revision 2.0 Complete Schematic Assembly Drawing Bill of Material Default configuration summary AT88CK109BK3, revision 1.0 Complete Schematic ...
Page 25
AT88CK109STK3 Figure 1. AT88Microbase Schematic, 1 of 4 AT88CK109STK3 User Guide 8699A—CRYPTO—10/09 Downloaded from Elcodis.com electronic components distributor...
Page 26
Figure 2. AT88Microbase Schematic, 2 of 4 Downloaded from Elcodis.com electronic components distributor...
Page 27
AT88CK109STK3 Figure 3. AT88Microbase Schematic, 3 of 4 AT88CK109STK3 User Guide 8699A—CRYPTO—10/09 Downloaded from Elcodis.com electronic components distributor...
Page 28
Figure 4. AT88Microbase Schematic, 4 of 4 Downloaded from Elcodis.com electronic components distributor...
Page 29
AT88CK109STK3 Figure 5. AT88Microbase Assembly Drawing, 1 of 2 ( Top side ) AT88CK109STK3 User Guide 8699A—CRYPTO—10/09 Downloaded from Elcodis.com electronic components distributor...
Page 30
Figure 6. AT88Microbase Assembly Drawing, 2 of 2 ( Bottom side ) Downloaded from Elcodis.com electronic components distributor...
Page 31
Transistor SOT23-3 MMBTA42LT1G 0.1" Pitch JTAG 2x5 Male Header RA TSW-105-16-L-D-RA 0.1" Pitch PORT-D Interface 2x5 Male Header PBC05DAAN B121 Buzzer SMT-0540-S-R B151 Push Button PTS635SL25SMTR LFS DPDT switch CAS-220TA AT88CK109STK3 User Guide 8699A—CRYPTO—10/09 Downloaded from Elcodis.com electronic components distributor...
Page 32
Figure 7. AT88CK109BK3 Schematic, 1 of 3 Downloaded from Elcodis.com electronic components distributor...
Page 33
AT88CK109STK3 Figure 8. AT88CK109BK3 Schematic, 2 of 3 7-10 AT88CK109STK3 User Guide 8699A—CRYPTO—10/09 Downloaded from Elcodis.com electronic components distributor...
Page 34
Figure 9. AT88CK109BK3 Schematic, 3 of 3 Downloaded from Elcodis.com electronic components distributor...
Page 35
AT88CK109STK3 AT88CK109BK3 Assembly Drawing, 1 of 2 ( Top side ) 7-12 AT88CK109STK3 User Guide 8699A—CRYPTO—10/09 Downloaded from Elcodis.com electronic components distributor...
Page 36
Figure 10. AT88CK109BK3 Assembly Drawing, 2 of 2 ( Bottom side ) Downloaded from Elcodis.com electronic components distributor...
Page 37
S1-2 CryptoAuthentication Socket SOT23-3 499-P36-20 H1-5, 2PIN HEADER VERT 2POS .100 TIN PBC02DAAN Interconnect PORT-D 10 Pin 2x5 VERT .100 10POS Fem SSW-105-01-G-D K1-2 Switch DPDT Surface Mount CAS-220TA 7-14 AT88CK109STK3 User Guide 8699A—CRYPTO—10/09 Downloaded from Elcodis.com electronic components distributor...
Page 38
POSSIBILITY OF SUCH DAMAGES. Atmel makes no representations or warranties with respect to the accuracy or completeness of the contents of this document and reserves the right to make changes to specifications and product descriptions at any time without notice. Atmel does not make any commitment to update the information contained herein.
