AT88SCK109STK3
Software Power
Configuration
H1 Mounted
H2 Not - mounted
Software Power
Configuration
H3 Mounted
H4 Not - mounted
Device Interconnect Header
3.10
Mapping AT88CK109BK3 to AT88Microbase, STK500 and STK600
3.11
3-14
8699A—CRYPTO—10/09
Downloaded from
Elcodis.com
electronic components distributor
HOST
This configuration allows the user to power cycle the
HOST socket via software. See Table 2 and 3 for
CLIENT
This configuration allows the user to power cycle the
CLIENT socket via software. See Table 2 and 3 for
The "INTERCONNECT" header provides a single-wire bus between the signal pins of the HOST
and CLIENT devices. The header can also serve as test points.
Figure 17. Interconnect Header
Px3
Maps to
AT88Microbase PB7
The AT88CK109BK3 maps to the 10-pin header of the AT88Microbase as follow:
Table 2.
Mapping the AT88CK109BK3 to the AT88Microbase
AT88Microbase
AT88CK109BK3
Header ( J1 )
PB0
Software Power Control
pinout details
pinout details
CLEINT
SIGNAL
INTERCONNECT
Comments
HOST Socket
HOST
SIGNAL
Px4
Maps to
AT88Microbase PB6
