Installation Instructions
Original Instructions
SynchLink Blocks
Catalog Numbers 1751-SLBA, 1751-SL4SP
This document describes how to install the 1751-SLBA SynchLink™ base block and the 1751-SL4SP 4-port splitter block.
Topic
Summary of Changes
This publication contains new and updated information as indicated in the following table.
Topic
1751-SL4SP module added to install
Page
3
4
5
6
7
8
8
9
10
11
11
11
Page
Throughout
3
11
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rockwell Automation Allen-Bradley SynchLink 1751-SLBA
Summary of Contents for Rockwell Automation Allen-Bradley SynchLink 1751-SLBA
-
Page 1: Table Of Contents
Installation Instructions Original Instructions SynchLink Blocks Catalog Numbers 1751-SLBA, 1751-SL4SP This document describes how to install the 1751-SLBA SynchLink™ base block and the 1751-SL4SP 4-port splitter block. Topic Page North American Hazardous Location Approval SynchLink Blocks Install the Block Wire the Base Block Wire the Splitter Block 1751-SLBA Indicators 1751-SL4SP Indicators... - Page 2 Indien de apparatuur wordt gebruikt op een wijze die niet is gespecificeerd door de fabrikant, dan bestaat het gevaar dat de beveiliging van de apparatuur niet goed werkt. Rockwell Automation Publication 1751-IN001B-EN-P - January 2017...
-
Page 3: North American Hazardous Location Approval
• Do not touch connectors or pins on component boards. • Do not touch circuit components inside the equipment. • Use a static-safe workstation, if available. • Store the equipment in appropriate static-safe packaging when not in use. Rockwell Automation Publication 1751-IN001B-EN-P - January 2017... -
Page 4: Synchlink Blocks
Module Locking Tab 1751-SL4SP Components Indicators Protective Caps Right-side and Left-side (not shown) Backplane Connectors Channel 1 Fiber Port Channel 2 Fiber Port Channel 4 Fiber Port Module Locking Tab Channel 3 Fiber Port 31201 Rockwell Automation Publication 1751-IN001B-EN-P - January 2017... -
Page 5: Install The Block
200 mm (7.8 in.) and use end-anchors appropriately. Be sure to ground the DIN rail properly. See Industrial Automation Wiring and Grounding Guidelines, Rockwell Automation publication 1770-4.1, for more information. To install the block on the DIN rail, follow these steps. -
Page 6: Wire The Base Block
IMPORTANT Make sure that the base block and splitter blocks are attached and secured before applying power to the base block. Failure to do so can damage the base block and companion blocks. Rockwell Automation Publication 1751-IN001B-EN-P - January 2017... -
Page 7: Wire The Splitter Block
Connect pre-terminated cables to the fiber-optic connectors as shown. Connect Channels 1…4 to the SynchLink Station Receivers. ATTENTION: Do not look directly into the fiber ports or fiber cables. Light levels can damage eyesight. Rockwell Automation Publication 1751-IN001B-EN-P - January 2017... -
Page 8: 1751-Slba Indicators
Channel 2 transmitter is on Channel 3 transmitter is on Channel 4 transmitter is on CH 1 CH 4 CH 3 CH 4 Power CH 1 CH 2 CH 2 CH 3 Power On Rockwell Automation Publication 1751-IN001B-EN-P - January 2017... -
Page 9: Mounting Dimensions
91.4 mm (3.6 in.) 98 mm Power On (3.81 in.) RxIN 751-SL4SP Mounting Dimensions 104 mm (4.084 in.) 70.1 mm (2.76 in.) 100 mm (3.94 in.) 91.4 mm (3.6 in.) 98 mm (3.81 in.) Rockwell Automation Publication 1751-IN001B-EN-P - January 2017... -
Page 10: Specifications
(22…12 AWG) stranded copper Wire size wire that is rated at 75 °C (167 °F), or greater, 1.2 mm (3/64 in.) insulation max Terminal block torque specs 5…7 lb•in. (0.56…0.79 N•m) North American Temp Code Rockwell Automation Publication 1751-IN001B-EN-P - January 2017... -
Page 11: Certifications
Provides declarations of conformity, certificates, and other certification details. http://www.rockwellautomation.com/global/certification/overview.page You can view or download publications at http://www.rockwellautomation.com/global/literature-library/overview.page. To order paper copies of technical documentation, contact your local Allen-Bradley distributor or Rockwell Automation sales representative. Rockwell Automation Publication 1751-IN001B-EN-P - January 2017... - Page 12 Rockwell Automation maintains current product environmental information on its website at http://www.rockwellautomation.com/rockwellautomation/about-us/sustainability-ethics/product-environmental-compliance.page. Allen-Bradley, Rockwell Automation, Rockwell Software, and SynchLink are trademarks of Rockwell Automation, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies. Rockwell Otomasyon Ticaret A.Ş., Kar Plaza İş Merkezi E Blok Kat:6 34752 İçerenköy, İstanbul, Tel: +90 (216) 5698400...
