Emerson Fisher FIELDVUE DVC6005 Series Instruction Manual Supplement page 6

DVC6005 Digital Valve Controllers
August 2017
Figure 2. ATEX Loop Schematics FIELDVUE DVC6005 HW2, and DVC6015, DVC6025, DVC6035
1 SEE NOTES IN FIGURE 5
GE60771 Sheet 13, Rev. D
6
ZONE 0, Ex ia IIC
ZONE 20, Ex ia IIIC
DVC6015, DVC6025,
DVC6035
Ui = 30 VDC
Ii = 100 mA
Ci = 0 uF
Li = 0 mH
Pi = 160 mW
NOTE 1, 3
1
ZONE 0, Ex ia IIC or Ex ia IIB
WITHOUT
I/O PACKAGE
T CODE
TYPE
T5
DVC6005
T6
Instruction Manual Supplement
ZONE 0, Ex ia IIC
REMOTE FIELD WIRING
TERMINAL BOX
Ex ia IIC or Ex ia IIB
TERMINALS
Uo = 30 VDC
Io = 21.2 mA
Po = 160 mW
Co = 55 nF
Lo = 78 mH
WITH
I/O PACKAGE
T CODE T AMB
T AMB
T5 ≤ 80_C
≤ 80_C
T6 ≤ 61_C
≤ 74_C
D104211X012
ZONE 0, Ex ia IIB ZONE 20, Ex ia IIIC
HW2 - WITH OR WITHOUT I/O PACKAGE
DVC6005
Ex ia IIC
LOOP TERMINALS
Ui = 30 VDC
Ii = 130 mA
Pi = 1.0 W
Ci = 15 nF
Li = 0.15 mH
*
AUX TERMINALS
AUX TERMINALS
Not Used
*Li = 0.15 mH WHEN THE AUX
TERMINALS ARE NOT USED OR IF
THEY ARE NOT PROVIDED
ZONE 20, Ex ia IIIC
WITHOUT
WITH
I/O PACKAGE I/O PACKAGE
MAX MAX
SURFACE T AMB SURFACE
TEMP TEMP
T91_C ≤ 80_C T104_C
T85_C ≤ 74_C T85_C
FIELD WIRING
TERMINAL BOX
Ex ia IIC
LOOP TERMINALS
Ui = 30 VDC
Ii = 101 mA
Pi = 757 mW
Ci = 15 nF
Li = 0.30 mH
Uo = 30 VDC
Io = 101 mA
Po = 757 mW
Co = 52.4 nF
Lo = 5.84 mH
T AMB
≤ 80_C
≤ 61_C
