Hardware Service Procedure
Replacing the Storage Shelf rail kit
Document number: 325
Version: 1.1 (05/02/2022)
Purpose
This document describes the process for replacing the 5U84 Storage Shelf rails.
Affected appliance models
3340 Appliance
3350 Appliance
5340/5340 HA Appliance
5350/5350 HA Appliance
Electrical Safety
The static discharged by human bodies can damage static-sensitive components on the boards.
When installing and maintaining the equipment, observe appropriate electrostatic safety precautions
to prevent personnel injuries or device damage.
When operating a device in an electrostatic sensitive area, you must take electrostatic-discharge
(ESD)-preventive measures. These include wearing ESD-preventive gloves, an ESD-preventive wrist
strap, and ESD-preventive clothes to avoid personnel injury or device damage.
To prevent damage to the device, pay attention to the following during operations:
Do not touch devices with bare hands because ESD from the human body may damage the
electrostatically sensitive elements on a board.
When dealing with the server or any of the internal components, wear an ESD-preventive wrist
strap, ESD-preventive gloves, and ESD-preventive suit.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 3340 and is the answer not in the manual?

Questions and answers

Summary of Contents for VERITAS 3340

  • Page 1 Replacing the Storage Shelf rail kit Document number: 325 Version: 1.1 (05/02/2022) Purpose This document describes the process for replacing the 5U84 Storage Shelf rails. Affected appliance models • 3340 Appliance • 3350 Appliance • 5340/5340 HA Appliance • 5350/5350 HA Appliance Electrical Safety The static discharged by human bodies can damage static-sensitive components on the boards.
  • Page 2: Removable Components

    About replacing the Veritas 5U84 Storage Shelf rails This document describes how to replace the rails for a Veritas 5U84 Storage Shelf. The rail kit replacement requires that the storage shelf be removed from the rack.
  • Page 3 HSP 325: 5U84 Storage Shelf Rail Kit Replacement • Disk drives in their DDIC carriers, including blanks Note: To help facilitate access to the storage shelf, remove the door from the rack. Prerequisites to beginning the storage shelf rail kit replacement The compute nodes and the storage shelves need to be powered off before the starting the storage shelf rail kit replacement.
  • Page 4 HSP 325: 5U84 Storage Shelf Rail Kit Replacement In Carrier must be returned to exactly the same disk drive drawer and disk drive slot once the storage shelf is returned to the rack. Note: Use removable labels to label the DDICs that you remove from the storage shelf disk drive drawers.
  • Page 5 HSP 325: 5U84 Storage Shelf Rail Kit Replacement Turn off any Expansion shelves in the same manner as you turned off the Primary Shelf. Loosen the plastic ties from the power cords near the connections on the shelf. Unplug the power cords. Removing a 5U84 Storage Shelf bezel Use this section to remove a storage shelf bezel.
  • Page 6 HSP 325: 5U84 Storage Shelf Rail Kit Replacement Note: Set the bezels and the screws aside in a secure location to be reinstalled on the 5U84 Storage Shelf. Repeat the steps above to remove the other bezel. Removing the disk drives in the 5U84 Storage Shelf Use the following procedures to remove and label the storage shelf disk drives.
  • Page 7 HSP 325: 5U84 Storage Shelf Rail Kit Replacement On the front panel of the bottom disk drive drawer, push the drawer latches inward and hold them in. While holding them in, pull the disk drive drawer all the way out until it locks open. Each 5U84 Storage Shelf can contain up to 84 disk drives in two drawers, which are accessible from the front of the storage shelf.
  • Page 8 HSP 325: 5U84 Storage Shelf Rail Kit Replacement Label the DDIC module with the slot numbers in which they are installed in the drive drawers. Use the following diagram to determine the slot numbers. On each DDIC module, push the drive carrier latch in the direction of the arrow. The Disk Drive In Carrier module unlocks and springs upward from the disk drive drawer.
  • Page 9 HSP 325: 5U84 Storage Shelf Rail Kit Replacement The disk drive drawer clicks when it is fully closed. 11 Use the screwdriver to rotate both anti-tamper locks until the arrows point towards the locked padlock icons. 12 Repeat this procedure to remove the DDIC modules and blanks in the top disk drive drawer. 13 When both disk drive drawers are empty and closed, lock the disk drive drawers using the screw driver with the Torx T20 bit.
  • Page 10 HA system. Note: The color of the fiber cables may be light blue or orange. (3340/3350/5350 Appliance) To remove the SAS3 data cables from the SAS3 Expansion ports of the SAS3 RAID controllers in a 3340/3350/5350 Appliance 5U84 Primary Storage Shelf: •...
  • Page 11 HSP 325: 5U84 Storage Shelf Rail Kit Replacement (5U84 Expansion Storage Shelf) To remove SAS3 data cables from a 5U84 Expansion Storage Shelf: Remove the SAS3 data cables from the Expansion Storage Shelf. Label the cables with the name of the ports from which you remove the cables. Warning: Note how the SAS3 cables are installed in the port before you remove it.
  • Page 12 HSP 325: 5U84 Storage Shelf Rail Kit Replacement Disconnect the power cables from both power supplies. Removing the rail fastening screws Use the following procedure to remove the rail fastening screws that secure the 5U84 Storage Shelf to the rack. To remove the rail fastening screws Remove the front and rear rail fastening screws from the front and rear of the rack rails.
  • Page 13 HSP 325: 5U84 Storage Shelf Rail Kit Replacement Remove the two clamping screws at the rear of the rails, with one screw on each side. Remove the two rear enclosure fastening screws at the rear of the rail, with one screw on each side.
  • Page 14 To remove the empty 5U84 Storage Shelf from the rack Using two people, slide the 5U84 Storage Shelf out from the rack. Note: Veritas recommends using removal straps such as shown in the following image to help move the empty storage shelf chassis from the rack.
  • Page 15 HSP 325: 5U84 Storage Shelf Rail Kit Replacement Place the 5U84 Storage Shelf in an out-of-the-way location. Removing 5U84 Storage Shelf rails from the rack Use the following procedure to remove the 5U84 Storage Shelf rails from the rack. To remove the 5U84 Storage Shelf rails from the rack Mark the location of the rails in the rack, if required, so the replacement rails can be installed in the same location.
  • Page 16 Use the following procedure to install the 5U84 Storage Shelf replacement rails in the rack. To install the storage shelf rails Veritas recommends that two people install the rails. One person works at the back of the rack and one person is at the front of the rack.
  • Page 17 HSP 325: 5U84 Storage Shelf Rail Kit Replacement Identify the left and the right rails which are labeled LH (left-hand) or RH (right-hand) on the front inside of the rail. Note the ledge at the bottom of each rail. The storage shelf sits on the ledges which must be positioned on the inside of the rack.
  • Page 18 HSP 325: 5U84 Storage Shelf Rail Kit Replacement Extend the rail assembly to enable the rear rail pins to engage. Verify that the pins are fully seated in the holes in the rack posts. Secure the four adjuster screws as needed. Do not over-torque. Repeat the process for the right rail.
  • Page 19 HSP 325: 5U84 Storage Shelf Rail Kit Replacement Descriptions of the screws are provided in the following table. Number Description Rack location(s) Rail location(s) Long fastening screw with two Front: Center holes in first Front: Top and bottom holes. washers - for use after shelf is and fifth rack units (RUs).
  • Page 20 HSP 325: 5U84 Storage Shelf Rail Kit Replacement Installing the rail fastening screws Use the following procedure to install the rail fastening screws that secure the 5U84 Storage Shelf to the rack. To install the rail fastening screws Install four enclosure fastening screws in the front 5U84 Storage Shelf rails. There are two screws on each side of the rack.
  • Page 21 HSP 325: 5U84 Storage Shelf Rail Kit Replacement Install the two rear enclosure fastening screws at the rear of the rail, with one screw on each side.
  • Page 22 HSP 325: 5U84 Storage Shelf Rail Kit Replacement Installing a 5U84 storage shelf into the rack Use the following procedure to install the 5U84 Storage Shelf into the rack. To install the 5U84 Storage Shelf into the rack Remove the caps from both sides of the front of the storage shelf. Warning: The shelf weighs 61.56kg (135.72lbs) without disk drives.
  • Page 23 HSP 325: 5U84 Storage Shelf Rail Kit Replacement Insert a small screw through the lock tab into the hole in the triangular end of the rail. Secure the screw. On the front of the storage shelf reattach the left and the right caps. The left cap contains the control panel.
  • Page 24 Put on a grounded ESD-compliant wrist strap or take other ESD-preventive measures. Locate the SAS3 cables that are connected to the 3340/3350/5350 Appliance compute nodes. They should have the temporary labels on them that indicate the ports in which to connect the...
  • Page 25 HSP 325: 5U84 Storage Shelf Rail Kit Replacement Connect the cables to the I/O module ports indicated on the temporary labels. Remove the labels after you connect the cable. (5U84 Expansion Storage Shelf) To connect SAS3 data cables to the 5U84 Expansion Storage Shelf chassis: Put on a grounded ESD-compliant wrist strap or take other ESD-preventive measures.
  • Page 26 HSP 325: 5U84 Storage Shelf Rail Kit Replacement If there are additional 5U84 Expansion Storage Shelves in the system, connect those SAS3 cables also. Remove the labels after you connect the cable. Installing the disk drives in the 5U84 Storage Shelf Use the following procedures to install the storage shelf disk drives in the chassis disk drive drawers.
  • Page 27 HSP 325: 5U84 Storage Shelf Rail Kit Replacement Take the DDIC that you labeled as 0 and place it into slot 0, with the drive capacity label facing you when you stand in front of the disk drive drawer. Continue populating the disk drive drawer with each DDIC, based on the label's slot number. There are two touch pads that are located on the top of each DDIC, which are used to secure the DDICs in the disk drive drawer slots.
  • Page 28 HSP 325: 5U84 Storage Shelf Rail Kit Replacement With one hand on each touch pad, push the DDIC downward and hold it down while sliding the DDIC forward into the driver carrier plate. This locks the DDIC in place, within the disk drive drawer. Check to ensure that the release latch has returned to its locked position.
  • Page 29 HSP 325: 5U84 Storage Shelf Rail Kit Replacement When you finish populating the disk drive drawers, double check each DDIC's release latch to ensure the latches are returned to their locked positions. Finally, remove all temporary labels from each DDIC when all of the DDICs have been returned to their original slot positions.
  • Page 30 HSP 325: 5U84 Storage Shelf Rail Kit Replacement 11 Push the disk drive drawer in slightly, and then release the latches. 12 Push the disk drive drawer all the way back into the 5U84 Storage Shelf, ensuring that it clicks into place.
  • Page 31: Starting The Appliance

    HSP 325: 5U84 Storage Shelf Rail Kit Replacement Installing a 5U84 Storage Shelf bezel Use this procedure to install a storage shelf bezel. Note: There are two bezels on the 5U84 Storage Shelves. Each bezel is installed the same way. To install a 5U84 Storage Shelf bezel Locate the bezel with the bright red swoosh in the front.
  • Page 32 PCIe Fibre Channel cards or SAS HBAs at the back of the compute node. Communication with the storage shelves should be normal. If faults are present or the compute node communication with the storage shelves is not functional, contact Veritas Technical Support.
