VERITAS 3340 Hardware Service Procedure

Veritas Appliance
Hardware Service Procedure
Replacing a faulty SAS3 data cable between a 3340 compute node
and the 5U84 Primary Storage Shelf
Document Number: 240
Version 1.0 (03/05/18)
Purpose
This document describes the process for replacing a faulty SAS3 data cable between a 3340 compute
node and the 5U84 Primary Storage Shelf.
Affected appliance models
• 3340 Appliance
Electrical Safety
The static discharged by human bodies can damage static-sensitive components on the boards.
When installing and maintaining the equipment, observe appropriate electrostatic safety precautions
to prevent personnel injuries or device damage.
When operating a device in an electrostatic sensitive area, you must take electrostatic-discharge
(ESD)-preventive measures. These include wearing ESD-preventive gloves, an ESD-preventive wrist
strap, and ESD-preventive clothes to avoid personnel injury or device damage.
To prevent damage to the device, pay attention to the following during operations:
• Do not touch devices with bare hands because ESD from the human body may damage the
electrostatically sensitive elements on a board.
• When dealing with the server or any of the internal components, wear an ESD-preventive wrist
strap, ESD-preventive gloves, and ESD-preventive suit.
About removing and replacing a faulty SAS3 cable between a 3340
compute node and the 5U84 Primary Storage Shelf
This section describes how to remove and replace damaged or faulty SAS3 data cables between a
3340 compute node and the 5U84 Primary Storage Shelf while the appliance operates. Because of
