VERITAS NetBackup 5340 Appliance Product Description

Hide thumbs Also See for NetBackup 5340:
Table of Contents

Advertisement

Quick Links

Veritas 5340 Appliance
Product Description
NetBackup™ 5340 Appliance and
Veritas™ Flex 5340 Appliance

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NetBackup 5340 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VERITAS NetBackup 5340

Summary of Contents for VERITAS NetBackup 5340

  • Page 1 Veritas 5340 Appliance Product Description NetBackup™ 5340 Appliance and Veritas™ Flex 5340 Appliance...
  • Page 2 Copyright © 2018 Veritas Technologies LLC. All rights reserved. Veritas, the Veritas Logo, Velocity, and NetBackup are trademarks or registered trademarks of Veritas Technologies LLC or its affiliates in the U.S. and other countries. Other names may be trademarks of their respective owners.
  • Page 3 Japan CustomerCare_Japan@veritas.com Documentation Make sure that you have the current version of the documentation. Each document displays the date of the last update on page 2. The latest documentation is available on the Veritas website: https://sort.veritas.com/documents Documentation feedback Your feedback is important to us. Suggest improvements or report errors or omissions to the documentation.

  • Page 4: Table Of Contents

    ....38 About Veritas 5340 Appliance storage shelves ........39 Available appliance storage options ........... 40 About the Veritas 5U84 Storage Shelf disk drive drawers ....43 5U84 Primary Storage Shelf and the 5U84 Expansion Storage Shelf control panel ............54 About the 5U84 Primary Storage Shelf and 5U84 Expansion Storage Shelf rear components ............
  • Page 5 Technical specifications, Environmental/Protocol standards, and Compliance standards ....75 5340 Appliance compute node technical specifications ......76 Veritas 5U84 Storage Shelf technical specifications ......79 Environmental specifications ............81 Protocol standards ................ 83 Regulatory, compliance, and certification information ......83 Product regulatory compliance ..........

  • Page 6: About The Veritas 5340 Appliance

    NetBackup Appliance software release 3.1 and above ■ The Veritas 5340 Appliance is a hardware and software storage system that scales up to a total of 1,920TiB (2,111TB) of usable backup capacity. It consists of one 2U 5340 Appliance compute node and one required externally attached 5U84 Primary Storage Shelf, which is used for data storage purposes.

  • Page 7: Features And Components Of The Appliance

    Primary Storage Shelf. SAS3 cables connect the 5U84 Primary Storage Shelf to the optional 5U84 Expansion Storage Shelves. Note: Veritas also offers a high availability (HA) multi-node solution for Veritas 5340 Appliance systems. Multi-node systems provide more efficient operation and improved aggregate performance for data protection operations.
  • Page 8 About the Veritas 5340 Appliance Features and components of the appliance Veritas 5340 Appliance system specifications (continued) Table 1-1 Technical Veritas 5340 Appliance system Specification RAID cache (each 32 GB appliance compute node) System memory (each Base memory capacity: 768GB...
  • Page 9 ■ to the rear extremity of the chassis) Note: The Veritas 5U84 Primary Storage Shelf and the 5U84 Expansion Storage Shelf are longer than what a standard IEC-compliant rack normally supports. Due to the additional length, the rack-based PDU hardware may need to be installed on the outside of the rack to accommodate the storage shelves.
  • Page 10 About the Veritas 5340 Appliance Features and components of the appliance Veritas 5340 Appliance system specifications (continued) Table 1-1 Technical Veritas 5340 Appliance system Specification Maximum weight Compute node: 23.26 kg (51.28 lbs) 5U84 Primary Storage Shelf: 135 kg (298 lbs) with drives; no rail 5U84 Expansion Storage Shelf: 135 kg (298 lbs) with drives;...
  • Page 11 IEC-60320-C13 plugs into an appliance or storage shelf power supply. Note: If your power distribution unit is not compatible with the IEC-60320-C14 plug, Veritas recommends that you purchase your power cable locally. Make sure the power cable meets or exceed the indicated power rating. “Power cables”...

  • Page 12: Locating The Appliance Serial Number

    About 5340 Appliance compute node disk drive configurations The Veritas 5340 Appliance compute node contains five 2 TB SAS hard disk drives. Each disk drive is accessible from the compute node's front panel. An embedded RAID controller on the compute node's mainboard configures four of the five disk drives into two mirrored RAID1 volumes.

  • Page 13: About The 5340 Appliance Compute Node Disk Drive Leds

    RAID rebuild operation. During the rebuild operation, the appliance dynamically accesses the hot-spare disk from slot 4 and uses it to rebuild the RAID volume. Veritas 5340 Appliance compute node front panel disk slot Figure 1-1 assignments...
  • Page 14 About the Veritas 5340 Appliance About 5340 Appliance compute node disk drive configurations 5340 Appliance compute node disk drive module LEDs Figure 1-2 Amber Status LED Green Activity LED The LED Status descriptions are described in the following table. 5340 Appliance compute node disk drive LED Status descriptions...

  • Page 15: About The 5340 Appliance Compute Node Front Panel Usb Port

    About the Veritas 5340 Appliance About the 5340 Appliance compute node front panel USB port About the 5340 Appliance compute node front panel USB port The 5340 Appliance compute node front panel includes a USB 2.0-compliant port that supports a data transfer rate of up to 480 Mb/second.
  • Page 16 (NMI), and then triggers the non-maskable interrupt. All server data can be lost. Veritas recommends that you do not enable NMI by pressing the NMI button. System Cold Reset Button When depressed, the System Cold Reset button (recessed, tool required for re-boots and re-initializes the appliance.

  • Page 17: About The System Status Led States

    About the Veritas 5340 Appliance About the 5340 Appliance control panel Control panel system LED descriptions (continued) Table 1-4 Label System information System Status LED The System Status LED is bi-color indicator that uses the colors green and amber to display the current health of the appliance.
  • Page 18 About the Veritas 5340 Appliance About the 5340 Appliance control panel System Status LED states Table 1-5 Color State Criticality Description Off - The Not ready System power is off (AC and/or DC) ■ color system is not System is in EuP Lot6 Off Mode ■...
  • Page 19 About the Veritas 5340 Appliance About the 5340 Appliance control panel System Status LED states (continued) Table 1-5 Color State Criticality Description Green ~1 Hz blink Degraded System degraded (continued): (continued) BMC booting Linux. (Indicated by Chassis ID ■ solid ON). System in degraded state (no manageability).

  • Page 20: About The Power Button Led States

    Unable to synchronize processor ■ frequency Unable to synchronize QPI link frequency ■ About the Power button LED states The Power button is located on the Veritas 5340 Appliance control panel. It is used to turn the appliance on and off.

  • Page 21: About The Appliance Compute Node Rear Panel

    About the Veritas 5340 Appliance About the appliance compute node rear panel Power button control panel location Figure 1-5 Power/Sleep button The following table provides a description of each power state. Power button LED states Table 1-6 State Power Mode...
  • Page 22 DB-15 VGA monitor connector Serial port - Serial connection for Veritas Technical Support use only Three stacked USB 3.0 Type A serial ports for general use IPMI port - An external RJ45 port used for appliance remote management...
  • Page 23 About the Veritas 5340 Appliance About the appliance compute node rear panel Compute node rear panel features and connectors (continued) Table 1-7 Number Function eth1/NIC2/host0 NetBackup Appliance (eth1/NIC2): ■ A 1-GbE port for general use. Flex Appliance (host0): ■ A 1-GbE port copper connector that you can connect to an administrative network to manage the 5340 Appliance system.
  • Page 24 You should not bond copper 1 Gb Ethernet ports that are installed in the appliance chassis with PCIe-based 10 Gb Ethernet Fibre Channel ports. Veritas appliances may include grounding studs in case your lab environment has such a requirement. The studs are located on the rear panel of the appliance. You can use standard grounding practices to connect grounding wires to the studs.

  • Page 25: Available 5340 Appliance Pcie-Based I/O Configurations

    25. Available 5340 Appliance PCIe-based I/O configurations The rear panel of the Veritas 5340 Appliance contains three PCIe riser card assemblies. PCIe riser card assemblies 1 and 2 each support three standard PCIe cards, while PCIe riser card assembly 3 supports two low profile PCIe cards. The slots are labeled 1 to 8.
  • Page 26 About the Veritas 5340 Appliance About the appliance compute node rear panel Note: A 5340 Appliance high availability (HA) configuration must use two identical 5340 compute nodes with regard to model number and hardware configuration. For example, you can use two 5340 compute nodes with configuration D. However, you cannot use one 5340 Appliance compute node with configuration D and one 5340 Appliance compute node with configuration B.
  • Page 27 About the Veritas 5340 Appliance About the appliance compute node rear panel Available 5340 Appliance PCIe-based I/O configurations Table 1-8 (continued) Slot Slot Slot Slot Slot Slot Slot Slot configuration option †† QLogic QLogic QLogic QLogic QLogic QLogic Reserved QLogic...

  • Page 28: Total 5340 Appliance On-Board And Pcie-Based I/O Ports

    QLE2692 16Gb HBA cards for PCIe slots other than slot 1 and slot 4 are available as add-on options after a NetBackup 5340 Appliance is purchased. * The 16Gb Fibre Channel HBA ports in slots 1 and 4 are used to connect the NetBackup 5340 Appliance compute node to the Veritas 5U84 Primary Storage Shelf.
  • Page 29 † Available only with NetBackup Appliance software release 3.1. NOTE: The 16Gb Fibre Channel HBA ports in slots 1 and 4 are used to connect the NetBackup 5340 Appliance compute node to the Veritas 5U84 Primary Storage Shelf. †† Available with NetBackup Appliance software release 3.1.2 and above.
  • Page 30 About the Veritas 5340 Appliance About the appliance compute node rear panel QLE2692 dual-port 16Gb Fibre Channel host bus adapter Table 1-10 specifications Item Description Bracket Full Height height Form factor Low-profile PCIe card (6.6 inches × 2.731 inches) Power 9.3 W...
  • Page 31 4Gbps link / input-output (I/O) activity On/Blink 8Gbps link / input-output (I/O) activity On/Blink 16Gbps link / input-output (I/O) activity To purchase a QLE2692 dual-port 16Gb Fibre Channel host bus adapter for your appliance, contact your Veritas sales representative, or your Veritas Partner representative.
  • Page 32 About the Veritas 5340 Appliance About the appliance compute node rear panel QLE2692 dual-port 16Gb Fibre Channel host bus adapter SKU Number Description 19441 QLOGIC 16Gb Fibre Channel host bus adapter QLE8442 dual-port 10Gb Ethernet/iSCSI capable card with SFP+ modules The QLE8442 is a dual-port 10GbE network interface card.
  • Page 33 Air flow 100 LFM at 55 C To purchase a QLE8442 dual-port 10Gb Ethernet card with SFP+ modules for your appliance, contact your Veritas sales representative, or your Veritas Partner representative. QLE8442 dual-port 10Gb Ethernet card with SFP+ modules SKU Number...
  • Page 34 About the Veritas 5340 Appliance About the appliance compute node rear panel QLE2562 dual-port 8Gb Fibre Channel host bus adapter port Table 1-13 specifications Item Description Bracket height Full Height Power 6.2 watts (typical) consumption (watts) Operating 0°C to 55°C (32°F to 131°F)

  • Page 35: 5340 Appliance Network Interface Card Port Assignments

    8Gbps link / input-output (I/O) activity activity To purchase a QLE2562 dual-port 8Gb Fibre Channel host bus adapter for your appliance, contact your Veritas sales representative, or your Veritas Partner representative. QLE2562 dual-port 8Gb Fibre Channel host bus adapter with SFP+ modules...
  • Page 36 About the Veritas 5340 Appliance About the appliance compute node rear panel NetBackup 5340 Appliance compute node Ethernet port Figure 1-10 assignments ETH4 ETH5 ETH7 ETH6 ETH11 ETH13 ETH12 ETH10 ETH2/ ETH2/ ETH3 ETH1/ ETH0/ ETH9 ETH8 IPMI NIC3 NIC3...
  • Page 37 (eth0) to an administrative network that does not provide any backup data transfer. For more information, see the NetBackup™ 53xx Appliance Initial Configuration Guide. Note: Veritas does not support forming a NIC bond using eth0/NIC1 with other eth/NIC ports. Flex Appliance (host1): ■...

  • Page 38: About The Veritas 5U84 Storage Shelves

    Chapter About the Veritas 5U84 Storage Shelves This chapter includes the following topics: About Veritas 5340 Appliance storage shelves ■ About the 5U84 Primary Storage Shelf and 5U84 Expansion Storage Shelf rear ■ components...

  • Page 39: About Veritas 5340 Appliance Storage Shelves

    About the Veritas 5U84 Storage Shelves About Veritas 5340 Appliance storage shelves About Veritas 5340 Appliance storage shelves Veritas offers two external storage shelf models for the Veritas 5340 Appliance. These include the: Veritas 5U84 Primary Storage Shelf (required) ■...

  • Page 40: Available Appliance Storage Options

    Available appliance storage options The Veritas 5340 Appliance compute nodes do not contain internal disk space on which to store data. Instead, the 5340 Appliance uses the required Veritas 5U84 Primary Storage Shelf as the main data storage device. The 5U84 Primary Storage Shelf connects to the 5340 Appliance compute nodes and uses RAID 6 drive sets to protect the stored data.
  • Page 41 5340 Appliance running NetBackup software using 4-TB and 8-TB disk capacities. Note: Veritas does not support mixing 4TB and 8TB disk drives within a storage shelf. Usable NetBackup 5340 Appliance 5U84 Storage Shelf storage...
  • Page 42 NetBackup 5340 Appliance software version 3.1.1 supports up to 960TiB (1,056TB) of usable MSDP storage capacity. For all storage configurations with an aggregate total of all MSDP pools equaling 960TB or larger, Veritas strongly recommends upgrading the memory capacity to 1536GB.

  • Page 43: About The Veritas 5U84 Storage Shelf Disk Drive Drawers

    MSDP storage if desired. The total amount of usable storage capacity depends on the number of storage shelves that are connected to the Flex compute node. ** For these storage shelf configurations, Veritas strongly recommends that you upgrade the memory capacity to 1.5TB, due to the increased resource requirements from updated MSDP encryption standards.
  • Page 44 About the Veritas 5U84 Storage Shelves About Veritas 5340 Appliance storage shelves Disk drive drawers 5U84 Primary Storage Shelf/5U84 Expansion Storage Shelf disk Figure 2-3 drive drawer The 5U84 Primary Storage Shelf and the 5U84 Expansion Storage Shelf each use a 5U chassis.
  • Page 45 About the Veritas 5U84 Storage Shelves About Veritas 5340 Appliance storage shelves In the bottom drive drawer, the drive slots are numbered from left to right, beginning with the first compartment that is closest to the front panel. The drive slots in this compartment are numbered 42 to 55.
  • Page 46 About the Veritas 5U84 Storage Shelves About Veritas 5340 Appliance storage shelves without turning off the 5U84 storage shelves. In addition, each DDIC prevents mis-alignment and damage to the disk drive connectors during the disk drive insertion and removal process.
  • Page 47 About the Veritas 5U84 Storage Shelves About Veritas 5340 Appliance storage shelves Disk Drive In Carrier (DDIC) module components and locations Figure 2-6 5U84 Storage Shelf DDIC component locations Table 2-3 Number Component Touch points Note: Touch points are used to facilitate the removal of the DDIC module from the storage shelf drawer.
  • Page 48 About the Veritas 5U84 Storage Shelves About Veritas 5340 Appliance storage shelves Disk Drive Drawer printed circuit board (PCB) assemblies Each disk drive drawer in a 5U84 storage shelf uses a printed circuit board (PCB) assembly to provide the electrical connectivity to the drawer's disk drives.
  • Page 49 About the Veritas 5U84 Storage Shelves About Veritas 5340 Appliance storage shelves Each PCB assembly contains two Drawer Sideplane cards. One Sideplane card mounts on the right side of the disk drawer, while the other card mounts on the left side of the drawer.
  • Page 50 About the Veritas 5U84 Storage Shelves About Veritas 5340 Appliance storage shelves Drawer Baseplane example Figure 2-9 Drawer Sideplane Status panels Drawer Sideplane Status panels are located on the front of the 5U84 storage shelves. These panels provide status and the activity information about the Sideplane card.
  • Page 51 About the Veritas 5U84 Storage Shelves About Veritas 5340 Appliance storage shelves 5U84 Primary Storage Shelf / 5U84 Expansion Storage Shelf Figure 2-11 Drawer Sideplane Status panel Drawer Sideplane Status panel descriptions Table 2-5 Number Item Sideplane card OK / Power good...
  • Page 52 About the Veritas 5U84 Storage Shelves About Veritas 5340 Appliance storage shelves Drawer Sideplane LED statuses (continued) Table 2-6 Status Power Drawer Fault Cable Fault Logical Fault Activity Bar Graph (Green) (Amber) (Amber) (Amber) (Green) Drive failure has occurred causing...
  • Page 53 About the Veritas 5U84 Storage Shelves About Veritas 5340 Appliance storage shelves Drawer Sideplane hot-swap LED location Figure 2-12 indicators Surrounding metal frame The following table describes the Drawer hot-swap Sideplane LED indicator statuses. Drawer Sideplane Hot-swap LED indicator statuses...

  • Page 54: 5U84 Primary Storage Shelf And The 5U84 Expansion Storage Shelf Control Panel

    About the Veritas 5U84 Storage Shelves About Veritas 5340 Appliance storage shelves 5U84 Primary Storage Shelf and the 5U84 Expansion Storage Shelf control panel The control panel is installed on the left side of both the 5U84 Primary Storage Shelf and the 5U84 Expansion Storage Shelf. It is functionally the same for both systems.

  • Page 55: About The 5U84 Primary Storage Shelf And 5U84 Expansion Storage Shelf Rear Components

    About the Veritas 5U84 Storage Shelves About the 5U84 Primary Storage Shelf and 5U84 Expansion Storage Shelf rear components Control panel functions and descriptions Table 2-8 Number Function Description Unit Identification The Unit Identification Display is a dual digit display that Display provides information about the storage shelf.
  • Page 56 About the Veritas 5U84 Storage Shelves About the 5U84 Primary Storage Shelf and 5U84 Expansion Storage Shelf rear components Fan modules ■ Power Supply Units (PSUs) ■ 5U84 Primary Storage Shelf rear components Figure 2-15 5U84 Primary Storage Shelf rear component locations...
  • Page 57 About the Veritas 5U84 Storage Shelves About the 5U84 Primary Storage Shelf and 5U84 Expansion Storage Shelf rear components 5U84 Expansion Storage Shelf rear components Figure 2-16 5U84 Expansion Storage Shelf rear component locations Table 2-10 Letter Item Expansion I/O modules...

  • Page 58: Veritas 5U84 Primary Storage Shelf Raid Controllers

    62. Veritas 5U84 Primary Storage Shelf RAID controllers The Veritas 5U84 Primary Storage Shelf uses dual, hot swappable Fibre Channel RAID controllers. These controllers create and manage the 5U84 Primary Storage Shelf disk drive RAID sets that contain backed up data. They also create and manage the RAID sets on 5U84 Expansion Storage Shelves when those are attached to the 5U84 Primary Storage Shelf.
  • Page 59 Veritas 5U84 Primary Storage Shelf Fibre Channel RAID Figure 2-17 controller The following figure and table provides component details for the Veritas 5U84 Primary Storage Shelf Fibre Channel RAID controller modules. Veritas 5U84 Primary Storage Shelf Fibre Channel RAID Figure 2-18...
  • Page 60 About the Veritas 5U84 Storage Shelves About the 5U84 Primary Storage Shelf and 5U84 Expansion Storage Shelf rear components The following figure and table provides component details for the Veritas 5U84 Primary Storage Shelf Fibre Channel RAID controller modules. Veritas 5U84 Primary Storage Shelf Fibre Channel RAID...
  • Page 61 About the Veritas 5U84 Storage Shelves About the 5U84 Primary Storage Shelf and 5U84 Expansion Storage Shelf rear components Veritas 5U84 Primary Storage Shelf Fibre Channel RAID Table 2-12 Controller indicator LED descriptions and definitions Description Definition Host 4/8/16Gb Fibre Off - No link detected.

  • Page 62: Veritas 5U84 Expansion Storage Shelf Expansion I/O Modules

    Cache Status LED support power on behavior and operational (cache status) behavior. When the port is down, both LEDs are off. Veritas 5U84 Expansion Storage Shelf Expansion I/O modules Veritas 5U84 Expansion Storage Shelf Expansion I/O modules provide SAS3 data throughput and communications between one or more 5U84 Expansion Storage Shelves.
  • Page 63 SAS3 ports - A, B, and C Ethernet port Note: Veritas does not use or support the Ethernet port. SAS Activity LEDs Expansion I/O module Status LED location and conditions This section discusses the location of the Status LEDs on the Expansion I/O modules and the Status LED conditions.
  • Page 64 About the Veritas 5U84 Storage Shelves About the 5U84 Primary Storage Shelf and 5U84 Expansion Storage Shelf rear components Expansion I/O module icon and Status LED conditions Table 2-14 Condition Activety LED (green) Fault LED (amber) The Expansion I/O module has encountered a fault condition.

  • Page 65: Veritas 5U84 Storage Shelf Cooling Modules

    Veritas 5U84 Storage Shelf cooling modules The Veritas 5U84 Storage Shelves include five cooling modules. The cooling modules provide cooling to the entire unit, which is suitable to maintain the internal component temperatures below each components maximum temperature limits.

  • Page 66: 5U84 Storage Shelf Power Supply Units

    PSUs are hot-swappable. You can replace a faulty PSU while the storage shelf is running. However, you must complete the PSU replacement procedure within two minutes after you remove the faulty PSU. Veritas 5U84 Storage Shelf chassis are keyed to prevent PSUs from being inserted upside down.
  • Page 67 About the Veritas 5U84 Storage Shelves About the 5U84 Primary Storage Shelf and 5U84 Expansion Storage Shelf rear components 5U84 Storage Shelf Power Supply Unit Figure 2-25 The rear panel of the PSU includes a power switch, three status LEDs, and an AC socket for the power cord.

  • Page 68: Veritas 5340 Appliance And 5U84 Storage Shelf Cables

    ■ Power cables Each of the AC power modules in both the Veritas 5340 Appliance and the required Veritas 5U84 Primary Storage Shelf accept one AC power cable. The optional 5U84 Expansion Storage Shelf also uses one AC power cord in each of its AC power modules.
  • Page 69 Cable rating: 15A 250V Note: If your power distribution unit is not compatible with the IEC-60320-C14 plug, Veritas recommends that you purchase your power cable locally. Make sure that the power cable meets or exceeds the indicated power rating. “ 5340 Appliance compute node technical specifications”...

  • Page 70: Network Cable

    Cable rating: 20A 250V Note: If your power distribution unit is not compatible with the IEC-60320-C20 plug, Veritas recommends that you purchase your power cable locally. Make sure that the power cable meets or exceeds the indicated power rating. “ Veritas 5U84 Storage Shelf technical specifications”...

  • Page 71: Multi-Mode Fiber Optic Cable

    73. Multi-mode fiber optic cable A Veritas 5340 Appliance compute node communicates with the required 5U84 Primary Storage Shelf through multi-mode fiber optic cables. One end of each fiber optic cable connects to PCIe-based 16Gb Fibre Channel host bus adapters that are installed in the compute node.

  • Page 72: Sas3 Cable

    70. “SAS3 cable” on page 72. “Twinaxial copper cables” on page 73. SAS3 cable SAS3 data cables are used to connect the 5U84 Primary Storage Shelf to an optional Veritas 5U84 Expansion Storage Shelf. SAS3 cables also connect multiple 5U84...

  • Page 73: Twinaxial Copper Cables

    Veritas 5340 Appliance and 5U84 Storage Shelf cables Twinaxial copper cables Expansion Storage Shelves to each other. SAS3 cables have SAS3 connectors on both ends. Two SAS3 cables ship with each Veritas 5U84 Expansion Storage Shelf. SAS3 cable Figure 3-5 “Power cables”...
  • Page 74 Veritas 5340 Appliance and 5U84 Storage Shelf cables Twinaxial copper cables “Power cables” on page 68. “Network cable” on page 70. “Multi-mode fiber optic cable” on page 71. “SAS3 cable” on page 72.

  • Page 75: Appendix A Technical Specifications, Environmental/Protocol Standards, And Compliance Standards

    Appendix Technical specifications, Environmental/Protocol standards, and Compliance standards This appendix includes the following topics: 5340 Appliance compute node technical specifications ■ Veritas 5U84 Storage Shelf technical specifications ■ Environmental specifications ■ Protocol standards ■ Regulatory, compliance, and certification information ■...

  • Page 76: 5340 Appliance Compute Node Technical Specifications

    SAS RAID PCIe card installed in a appliance compute node PCIe riser assembly RAID levels RAID1: Veritas 5340 Appliance compute node system disks Usable MSDP and AdvancedDisk storage capacity: up to 1920TiB (2,111TB) AdvancedDisk storage MSDP storage capacity: up to 960TiB (1,056TB) capacity (TB) “Available appliance storage options”...
  • Page 77 Technical Specification 5340 Appliance compute node Maximum number of storage shelves One Veritas 5U84 Primary Storage Shelf; three Veritas 5U84 Expansion Storage Shelves. I/O ports 16Gb Fibre Channel ports Up to 12, depending on the appliance I/O configuration “Available 5340...
  • Page 78 Note: If your power distribution unit is not compatible with the IEC-60320-C14 plug, then Veritas recommends that you purchase your power cable locally. Make sure the power cable meets or exceed the indicated power rating. AC Frequency range...

  • Page 79: Veritas 5U84 Storage Shelf Technical Specifications

    Veritas 5U84 Storage Shelf technical specifications Veritas 5U84 Storage Shelf technical specifications The following table provides technical specifications for both the Veritas 5U84 Primary Storage Shelf and the Veritas 5U84 Expansion Storage Shelf. Veritas 5U84 Primary Storage Shelf / 5U84 Expansion Storage...
  • Page 80 Technical specifications, Environmental/Protocol standards, and Compliance standards Veritas 5U84 Storage Shelf technical specifications Veritas 5U84 Primary Storage Shelf / 5U84 Expansion Storage Table A-2 Shelf technical specifications (continued) Technical specification Description Supported RAID level RAID6 and RAID10: 5U84 Primary Storage Shelf and 5U84...

  • Page 81: Environmental Specifications

    The non-operating temperature is defined as the temperature of the system when the system is turned off. It is also referred to as the storage temperature. Veritas recommends that you do not store the system in an environment where the temperatures fall outside of the listed temperature range.
  • Page 82 (feet) Temperature gradient 10°C/h (50°F/h) (per hour) Veritas 5U84 Primary Storage Shelf / 5U84 Expansion Storage Shelf environmental specifications Veritas 5U84 Primary Storage Shelf / 5U84 Expansion Storage Table A-4 Shelf environmental specifications Specification Description Temperature range Operating: 5º to 35ºC (de-rate 5ºC above 2,133m (7,000’)) (41°F to 95°F)

  • Page 83: Protocol Standards

    Technical specifications, Environmental/Protocol standards, and Compliance standards Protocol standards Protocol standards The following table provides standards with which the Veritas 5340 Appliance and the Veritas 5U84 Primary/Expansion Storage Shelf comply. Veritas Appliance / Veritas 5U84 Primary/Expansion Storage Table A-5 Shelf standards compliance...

  • Page 84: Product Regulatory Compliance

    Technical specifications, Environmental/Protocol standards, and Compliance standards Regulatory, compliance, and certification information To ensure regulatory compliance, you must adhere to the assembly instructions in this guide to ensure and maintain compliance with existing product certifications and approvals. Use only the described, regulated components that are specified in this guide.

  • Page 85: Product Emc Compliance - Class A Compliance

    Technical specifications, Environmental/Protocol standards, and Compliance standards Regulatory, compliance, and certification information CE - Low Voltage Directive 73/23/EEE (Europe) ■ IRAM Certification (Argentina) ■ GB4943- CNCA Certification (China) ■ Product EMC Compliance - Class A Compliance The following is a list of EMC compliance norms for different countries: FCC /ICES-003 - Emissions (USA/Canada) Verification ■...

  • Page 86: Certifications / Registrations / Declarations

    Technical specifications, Environmental/Protocol standards, and Compliance standards Regulatory, compliance, and certification information California Code of Regulations, Title 22, Division 4.5, Chapter 33: Best ■ Management Practices for Perchlorate Materials China - Restriction of Hazardous Substances (China RoHS) ■ WEEE Directive (Europe) ■...
  • Page 87 Technical specifications, Environmental/Protocol standards, and Compliance standards Regulatory, compliance, and certification information This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 88 Technical specifications, Environmental/Protocol standards, and Compliance standards Regulatory, compliance, and certification information CE Declaration of Conformity (Europe) This product has been tested in accordance to, and complies with the Low Voltage Directive (73/23/EEC) and EMC Directive (89/336/EEC). The product has been marked with the CE Mark to illustrate its compliance.

  • Page 89: Index

    Index Symbols 5U84 Storage Shelves (continued) Disk Drive In Carrier (DDIC) modules 45 16Gb Fibre Channel HBA 29 components and locations 47 5340 appliance compute node disk drive slot numbering 44 disk drive layout 12 plug-in modules 39 5U84 Expansion Storage Shelf printed circuit board (PCB) assembly about 39 Baseplane cards 48...
  • Page 90 LED location and conditions Disk drive drawers Expansion I/O modules 5U84 Storage Shelves 43 Veritas 5U84 Expansion Storage Shelf 63 Disk Drive In Carrier (DDIC) modules 5U84 Storage Shelves 45 components and locations 47 Network interface port locations and speeds 35...
  • Page 91 Veritas Appliance / Veritas 5U84 Technical specifications Primary/Expansion Storage Shelf 83 Veritas 5U84 Storage Shelf 79 technical specifications Veritas 5340 Appliance compute node 76 QLE8442 dual-port 10Gb Ethernet card dual-port 32 USB port compute node front panel location 15 RAID controller 58...
