Dräger Evita Infinity V500 Pocket Manual

Hide thumbs Also See for Evita Infinity V500:

Advertisement

Quick Links

Pocket Guide
Evita® Infinity V500
Software version 2.n

Advertisement

loading

Related Manuals for Dräger Evita Infinity V500

Summary of Contents for Dräger Evita Infinity V500

  • Page 1 Pocket Guide Evita® Infinity V500 Software version 2.n...

  • Page 2: Table Of Contents

    QUICK GUIDE EVITA® INFINITY V500 02 | Content System overview Operating concept Getting started Operation Alarms Monitoring The Evita® Infinity V500 Pocket Guide is not a replacement or substitute for the Instructions for Use. It is for informational purposes only. Any use of the device requires full understanding and strict observation of the Instruction for Use.
  • Page 3 | 03 Intended use Evita V500 ventilation unit The Evita V500 ventilation unit of the Infinity Acute Care System is intended for the ventilation of adults, paediatric patients and neonates. Evita V500 provides mandatory ventilation modes and ventilation modes for supporting spontaneous breathing and also airway monitoring.

  • Page 4: System Overview

    QUICK GUIDE EVITA® INFINITY V500 04 | System overview Intensive care Ventilator Display unit Infinity C500 Ventilation unit Gas supply unit GS500 Power supply unit PS500 Trolley with 4 brakes Evita® Infinity V500...
  • Page 5 | 05 System overview Cockpit Front Panel Alarm bar Touch screen ON/OFF button Rotary knob Audio (touch turn confirm) paused AC power LED – button lights up when the device is connected to AC power Battery LED – indicates battery status...
  • Page 6 QUICK GUIDE EVITA® INFINITY V500 06 | System overview Cockpit Back Panel Alarm bar VESA mounting holes USB ports Serial communication ports Isolated network Single link Digital connectors Visual Interface (DVI)
  • Page 7 | 07 System overview Ventilation unit, front panel Operation display Flap of ventilation Expiration valve Inspiration valve Expiratory flow sensor Emergency air intake Nebulizer port Water trap...

  • Page 8: Operating Concept

    QUICK GUIDE EVITA® INFINITY V500 08 | Operating concept Main screen Header Monitoring area with curves, loops, trends and measured values Main menu bar with buttons for opening dialog windows activating functions Therapy bar with the therapy controls for the ventilation parameters of the active ventilation mode...
  • Page 9 | 09 Operating concept Main screen Patient System data, Therapy status: Alarms, messages Alarm status: category e.g., state of Therapy type, and instructions Alarm silence and display of charge of the ventilation mode, for the user remaining time batteries additional settings...
  • Page 10 QUICK GUIDE EVITA® INFINITY V500 10 | Operating concept Alarm priorities A certain priority, indicating the urgency, is assigned to each alarm. The following table shows the differences between the alarm priorities with respect to identification and the action required. Colour Alarm priority Action required...
  • Page 11 | 11 Operating concept Touch – Turn – Confirm Selecting and setting parameters and functions Touch Turn Confirm the control element. the rotary knob to the right or by pressing the rotary knob. The control element to the left to make the setting. The setting is applied, and turns yellow.

  • Page 12: Getting Started

    QUICK GUIDE EVITA® INFINITY V500 12 | Getting started Switching on Evita V500 and Infinity C500 Prerequisites: – Evita V500, Infinity C500, Ventilation unit, PS500 and GS500 are left side: reprocessed and assembled Toggle switch – The mains power supply and the gas supply are connected.
  • Page 13 | 13 Getting started Selecting the breathing circuit and the breathing gas humidifier 1. Touch the Start/ Standby ... button in the main menu bar. 2. Touch the Br. circuit/ Humidifier tab. 3. Touch the button ▼. 3./4. 4. Select the breathing circuit used from the selection list.
  • Page 14 QUICK GUIDE EVITA® INFINITY V500 14 | Getting started Performing the breathing circuit check After the device check the user is requested to perform the check of the breathing circuit. Prerequisite: The System check page is opened. 1. Touch the Breathing circ. check tab.
  • Page 15 | 15 Getting started Setting ventilation Ventilation parameter start-up settings by patient category The Start/Standby page contains the buttons for the patient category: – New Adult – New Ped. pat. – New Neo. 1. Touch the button for the desired patient category.
  • Page 16 16 | QUICK GUIDE EVITA® INFINITY V500 Getting started Selecting the Tube or NIV application mode Evita V500 can switch between non-invasive ventilation and tube ventilation. The application mode can only be selected in standby mode. 1. Touch the Start/ Standby ... button in the main menu bar.

  • Page 17: Operation

    | 17 Operation Setting ventilation Opening the Ventilation settings dialog window. The Ventilation settings dialog window can be opened as follows: 1. Touch the Ventilation settings ... button in the main menu bar.  2. Touch the button in the therapy bar.
  • Page 18 QUICK GUIDE EVITA® INFINITY V500 18 | Operation Setting ventilation parameters 1. Prerequisite: The General settings page is opened. 2. Touch the corresponding therapy control, e. g., RR. The colour turns yellow. 3. Set the value by turning the rotary knob and push to confirm. 4.
  • Page 19 | 19 Operation Switching on O Therapy 1. O therapy can only be switched on in standby mode. Touch the Start/ Standby ... button in the main menu bar. Evita V500 opens the Start/Standby dialog window. 2. Touch the Standby button and confirm with the rotary knob.

  • Page 20: Alarms

    QUICK GUIDE EVITA® INFINITY V500 29 | Alarms Display of alarms Optical alarm signals Alarm bar Alarm message field Blinking parameter field Display of alarms – Acoustic alarm signals Evita V500 generates different alarm tone sequences to indicate alarms acoustically. The acoustic alarm signal can be suppressed for 2 minutes maximum.
  • Page 21 | 21 Alarms Displaying current alarms To display the current alarms, proceed as follows: 1. Touch the alarm message in the header bar. 2. Touch the Alarms ... button in the main menu bar. 3. Touch the Current alarms tab. Acknowledging all alarm messages that are no longer active: 4.

  • Page 22: Monitoring

    QUICK GUIDE EVITA® INFINITY V500 22 | Monitoring Installing the CO sensor and CO cuvette 1. Insert the plug of the CO sensor into the socket at the rear of the ventilation unit. 2. Insert the cuvette into the patient port of the Y-piece.
  • Page 23 | 23 Monitoring Performing a CO zero calibration Zero calibration is performed in ambient air and with a clean sensor which is removed from the cuvette. Prerequisite: Evita V500 is switched on and at least the three minute warm up phase for the CO sensor has elapsed.
  • Page 24 Not all products, features, or services are for sale in all countries. Mentioned Trademarks are only registered in certain countries and not necessarily in the country in which this material is released. Go to www.draeger.com/trademarks to find the current status. CORPORATE HEADQUARTERS Drägerwerk AG &...
