WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury,
death, or property damage.
— Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not use any
phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbour's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a qualified
installer, service agency or the gas fitter.
Installation & Maintenance Manual
SIT-WIFI
WIFI DONGLE
• The installation of this fireplace must be done by a
®
• Check local codes and read all instructions prior to
C
US
qualified and certified gas appliance installer.
installation.
NOTICE
Installer: Leave this manual with the appliance.
Consumer: Retain this manual for future reference.
CAUTION
Installation and service must be performed by a qualified installer,
service agency or the gas fitter.
DANGER
Read and understand this manual. Improper installation, adjustment,
alteration, service or maintenance can cause serious injury, property
damage or even death. For assistance or additional information
consult a qualified installer, service agency or the gas supplier.
WARNING
Some materials used in the manufacturing process of this product can
expose you to Benzene which is known in the State of California to
cause cancer and birth defects or other reproductive harm. For more
information go to www.P65warnings.ca.gov
XG0681 - 090222

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIT-WIFI and is the answer not in the manual?

Questions and answers

Summary of Contents for Montigo SIT-WIFI

  • Page 1 Installation & Maintenance Manual SIT-WIFI WIFI DONGLE • The installation of this fireplace must be done by a qualified and certified gas appliance installer. ® • Check local codes and read all instructions prior to installation. NOTICE WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, Installer: Leave this manual with the appliance. death, or property damage.
  • Page 2: Safety Alert Key

    SIT Proflame2 Connect enabled remote SIT PN: 0.584.080 (handheld remote) Montigo PN: GC3105 (handheld remote) SIT PN: 0.584.090 (wall mounted remote) Montigo PN: EC1550 (wall mounted remote) This can be identified by the "connect" icon on the upper right corner of the label. Proflame Connect App (not Proflame Connect Plus) Android and iOS applications can be found in their respective stores: Play Store and App Store.
  • Page 3: Dongle Installation

    General Dongle Installation To install the Proflame Connect kit it is necessary to turn off the gas appliance and to disconnect the power supply, wait for the unit to fully cool. To the install the dongle: Unless a compatible board is already installed, remove the old IFC and replace it with the compatible IFC, (The dongle compatible IFC boards are distinguished by their green schematic on the front).
  • Page 4 General Configure a fireplace with the app If you want to use your fireplace with Virtual Assistants, please insert below the 8-character pairing key that you received via email. To get the key to use voice commands you need to register (Android) your device on the registration web page, if you don't want to use voice commands, leave the field blank and press next.
  • Page 5 General Configure a fireplace with the app (iPhone) Put the dongle in configuration mode keeping the button pressed until green and red lights turn on. 8. When the fireplace is detected, press the Next button. 9. Enter your WiFi password and press Next. Connect the mobile device to the local WiFi network.
  • Page 6: Change Temperature Units

    General Search for new fireplaces just Change temperature units configured In the top left hamburger menu, the temperature unit switch changes the temperature unit displayed in the whole application. All showed Configured fireplaces, connected to the local WiFi network, must be temperatures in the application are converted, with the related found by the application.
  • Page 7: Fireplace Controls

    General Fireplace controls All available controls of each fireplace are reachable from the main page of the application. The displayed status reflects the status of the selected fireplace, showed on the top right area. More users can control a fireplace at the same time. When a user sends a command, this command is reflected to all users working on that fireplace.
  • Page 8 Installation & Maintenance Manual SIT-WIFI SIT-WIFI Wifi dongle Wifi dongle XG0681 - 090222...
