Symmons Ballina 522TS Operation & Maintenance Manual

Non-diverter tub spout

Advertisement

Quick Links

522TS
Ballina
Non-Diverter Tub Spout
Operation & Maintenance Manual
Model Numbers
522TS
Non-Diverter Tub Spout
Modifications
-BBZ
Brushed bronze finished
-STN
Satin nickel finish
Note: Append appropriate -suffix to model number.
Dimensions
A A
Note: Dimensions are subject to change without notice.
Symmons Industries, Inc.
©2014 Symmons Industries, Inc.
B B
C C
D D
31 Brooks Drive
Braintree, MA 02184
www.symmons.com
Specifications
Non-diverter tub spout made from brass plated in
standard polished chrome finish.
Warranty
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
Measurements
A
B
C
D
Required for Installation
Plumber tape
(800)796-6667
gethelp@symmons.com
ZV-3089 REV 0 09/02/2014
Ø 2 1/2", 64 mm
7", 178 mm
1/2", 13 mm
1/2" NPT
Fax: (800)961-9621
