Shower Valve Trim
Ligature resistant
Installation Brief
Model Number
5700-TRM .........Shower Valve Trim
(shower control valve not included)
Tools & Materials
1/8" hex wrench included
Visual Installation Guide
Knob kit
RTS-028
1/8" hex wrench included
Note: Valve, piping, and ttings are not included. Actual plumbing
should be determined and installed by a licensed plumber.
Lig-Res
5700-TRM
Disclaimers
Product is designed to reduce
■
likelihood that unit can be used
as a device for hanging.
Product is not a substitute for
■
the evaluation, treatment or
appropriate supervision of
persons at risk of suicide.
Lig-Res Shower Valve Trim, 5700-TRM
Escutcheon kit
RTS-027
Dome cover
™
Need Help?
Symmons customer service:
Phone: (800) 796-6667
customerservice@symmons.com
Mon - Fri 7:30 am - 7:00 pm EST
www.symmons.com/service
• Technical help
• Product information
• Warranty policy
Care and cleaning
Clean finished area using mild soap
or a non-abrasive cleaner and then
quickly rinse with water. A non-
abrasive wax may be used to preserve
finish area.
Escutcheon
Advertisement
Related Manuals for Symmons Lig-Res 5700-TRM
Summary of Contents for Symmons Lig-Res 5700-TRM
- Page 1 Installation Brief Model Number Disclaimers Need Help? 5700-TRM ..Shower Valve Trim Symmons customer service: Product is designed to reduce ■ (shower control valve not included) likelihood that unit can be used Phone: (800) 796-6667 as a device for hanging.
- Page 2 (73 mm) Notes: Dimensions subject to change without notice ■ ■ ■ ■ Symmons Industries, Inc. 31 Brooks Drive Braintree, MA 02184 (800)796-6667 Fax: (800)961-9621 ■ ■ ■ ■ ©2015 Symmons Industries, Inc. Printed in U.S.A. www.symmons.com gethelp@symmons.com ZV-1085 03112015...
