Marshall Electronics V-RD151-4 Specifications

15" Rack Mountable Pull-Out Drawer LCD Panel
V-RD151P
with Audio
Display (Viewing area)
15.1" (11.69" x 9.12")
Resolution (Pixels) 1024 H x RGB x 768 V
Dot Pitch 0.297 mm x 0.302 mm
Brightness (in cd/m²) 250 cd/m²
System
NTSC/PAL auto rec
Inputs per panel (total) Video: 1 S-Video, 1 Composite, 1 XGA.
Audio: 2 Unbalanced RCA
Dimensions
19.12"W x 1.75"H x 22"D
Approx. Weight 9.5 lbs
Power Consumption 12 VDC, 2.0 Amps
Save rack space with our monitor in a drawer model V-RD151P . A high-resolution 15" active matrix TFT
display features CRT style viewing angles and is designed to collapse into a single 1RU high (1.75-inch)
space when not in use. This model is often used in remote, ENG and EFP vehicles as a video and audio
program monitor and provides large screen viewing of a video feed to a satellite uplink or for use with
a laptop editing system. XGA/VGA, Y/C (S-Video) and composite inputs are provided along with stereo
audio. All connections are accessed from the rear of the drawer enclosure and include loop through for
each signal. When the display is closed into the drawer, a keyed lock is provided for secure transport.
Power supply and owners manual are included.
·
High Resolution 1024 x 768 pixels, 786,432 total
·
Bright 250 cd/m² candle luminance
·
Video and S-Video inputs with 75Ω termination and active loop through feature
·
Ultra-compact design fits in 19-inch EIA standard rack 1U high
·
Built-in Speakers
·
NTSC/PAL auto recognition
·
Key lock for secure transportation
Price: $2199.00
Inputs
Composite
S-Video
XGA
Audio
Another space saving monitor in a drawer is the 15" V-RD151-4. This model features a Quad Split and
Sequential Switcher for composite video signals. The 1024 x 768 display produces a high resolution
image. A Quad Split feature allows any mix of the four composite video channels to appear on the moni-
tor as real time picture-in-picture images. For added flexibility, this unit can accommodate composite
video, Y/C (S-Video) or XGA computer signals for monitoring (S-Video and XGA inputs are only available
in full screen mode). All connections are accessed from the rear of the drawer enclosure and include
a loop through for each signal. When the display is closed into the drawer, a keyed lock is provided for
secure transport. Power supply and owners manual are included.
·
·
·
·
·
·
·
8 0 0 - 8 0 0 - 6 6 0 8 w w w . L C D R a c k s . c o m
•
15" Rack Mountable Pull-Out Drawer LCD Panel with
V-RD151-4
Built-in Quad Splitter
Display (Viewing area)
15.1" (11.69" x 9.12")
Resolution (Pixels) 1024 H x RGB x 768 V
Dot Pitch 0.297 mm x 0.302 mm
Brightness (in cd/m²) 250 cd/m²
System
NTSC: V-RD151-4, PAL: V-RD151-4-PAL
Inputs per panel (total) 1 S-Video, 4 Composite, 1 XGA
Dimensions 19.12"W x 1.75"H x 22"D
Approx. Weight 10 lbs
Power Consumption
12 VDC, 2.5 Amps
High Resolution 1024 x RGB x 768 pixels, 786,432 total
Bright 250 cd/m² candle luminance
4 Video inputs with 75Ω termination and active loop through feature
Ultra-compact design fits in 19-inch EIA standard rack 1U high
Built-in Quad Splitter/Sequential Switcher
Available in NTSC or PAL format
Key lock for secure transportation
LCD Racks / Pull out Drawers 25
Price: $2699.00
Inputs
Composite
S-Video
XGA
