Summary of Contents for Thermo Scientific Precision WB159915
- Page 1 Precision Water Bath ™ Catalog No. WB159915, WB161015S, WB160025, WB160535, WB160635, WB160745, WB160855, WB159910-33, WB161010S-33, WB160020-33, WB160530-33, WB160630-33, WB160740-33, WB160850-33 LTM1599X1 • 7/8/08...
-
Page 2: Table Of Contents
Table of Contents Introduction................................3 Safety Information ..............................5 Alert Signals..............................5 Specifications ..............................7 Water Bath Models Available........................7 Unpacking and Installation ..........................8 Packing List ..............................8 Assembly and Installation ..........................8 Repositioning the Control Panel ........................9 Filling the Unit ............................10 Controls and Indicators ..........................10 Operation ................................12 Power Up ..............................12 Setting the Temperature Units to ºF or ºC ....................13 Setting the Temperature Setpoint ......................13... -
Page 3: Introduction
Introduction Congratulations on your new Thermo Scientific Precision Water Bath. Precision Water Baths offer the versatility needed to han- dle virtually any clinical laboratory procedure — incuba- tion, inactivation, agglutination — as well as most serolog- ical, pharmaceutical, biomedical, and industrial proce- dures. - Page 4 NTRODUCTION The calibration of the water bath can be adjusted to opti- mize its accuracy for the temperature that is used most often in your application. This can be accomplished through a simple procedure accessed from the front panel. As a convenience, a drain pump is supplied with 10, 20, 28, and dual 5/10 liter models.
-
Page 5: Safety Information
Safety Information Alert Signals These instructions contain important operating and safety information. The user must carefully read and understand these instructions before using the water bath. Your unit has been designed to optimize function, reliability, Warning safety, and ease of use. It is the userʼs responsibility to install Warnings alert you to a possibility of the bath in conformance with local electrical codes. - Page 6 AFETY NFORMATION - Weak salt solutions containing sodium chloride, calcium chloride, chromate or chromium com- pounds. - High Purity water (distilled water, deionized water, reverse osmosis, etc.) - Most photographic solutions. • Do not use a flammable liquid. A fire hazard may result.
-
Page 7: Specifications
Specifications Water Bath Models Available These are nominal specifications. We reserve the right to change specifications or designs at any time without Capacity/Type Model No. 120 VAC 230 VAC incurring obligation. 2 liter WB159915 WB159910-33 Single chamber SS LID Power requirements 120 VAC or 230 VAC ±... -
Page 8: Unpacking And Installation
The water bath is shipped in a single carton. When unpacking the unit, check each loose item against the packing list below. Should a shortage exist, notify your Thermo Scientific branch or representative, identifying the part by name and catalog number. Note... -
Page 9: Repositioning The Control Panel
NPACKING AND NSTALLATION Install the cover by inserting the hinge into the lip at the rear of the bath. Angle the cover up while push- ing down to lock the hinge in place under the stain- less steel tank lip. Remove the cover by lifting the lid and pushing the hinge towards the back to release it from under the tank lip. -
Page 10: Filling The Unit
NPACKING AND NSTALLATION Filling the Unit Follow these steps to fill the unit in preparation for use: Fill the water bath with tap water or oil so that the liquid level is approximately 1 1/2 inches (3/4 inch with 2 liter shallow model) from the top of the tank when full anticipated load is placed in bath. - Page 11 NPACKING AND NSTALLATION Program: Lights to show that unit is in program mode rather than run mode; see menu below. Heat: Lights to show when heat is being sup- plied to the chamber; cycles on and off as heat is requested by the controller. Menu: Allows you to select the mode of opera- tion.
-
Page 12: Operation
Operation Follow these procedures for the operation of the unit, including: •Power up and initial indications. •Setting the temperature units in ºF or ºC. •Setting the temperature setpoint. •Setting the backup temperature. •Calibrating the unit. •Emptying and cleaning the unit. Power Up Follow these steps to turn on the unit to prepare it for use: Set the power switch to the ON position. -
Page 13: Setting The Temperature Units To ºf Or ºc
PERATION Setting the Temperature Units to ºF or ºC Note which indicator is lit to the left of the display, either F for Fahrenheit or C for Centigrade. If the desired indicator is lit, omit this procedure. To change the temperature units, follow this procedure: Press Menu button so display shows _C_F. -
Page 14: Setting The Safety Temperature
PERATION Setting the Safety Temperature Follow these steps to set the water bath Safety tempera- ture controller. Set the Temperature set point 2 to 5 degrees higher than desired temperature. Wait until bath temperature stabilizes as shown by displayed actual temperature. Turn backup controller knob counterclockwise until Alarm light just comes on. -
Page 15: Emptying And Cleaning The Unit
PERATION the Set button when you have achieved the desired setting. The display will return to normal Note operation within a few seconds, displaying the The temperature offset can be set up actual temperature. to a range of 5.5ºC or 10.0ºF. In the example above, you would set the display to read -1. -
Page 16: Troubleshooting
Troubleshooting If you have problems using the unit, follow these general procedures to track down the cause from the symp- toms you are experiencing. If an error message appears on the display, refer to the specific error in this chart. If the problem is not resolved using the table below, contact Technical Support at 1-800-553-0039. -
Page 17: Replacement Parts
Replacement Parts Item Part No. Stainless Steel Lid Cover, 2 liter 15-462-32 Stainless Steel Lid Cover, 2 liter shallow and 5 liter 15-462-33 Stainless Steel Lid Cover, 10 liter 15-462-34 Stainless Steel Lid Cover, 20 and 28 liter 15-462-35 Hinge, lid (for 2 liter) SPN102383 Hinge, rim (for 2 liter) SPN102384... -
Page 18: Schematics
Schematics... -
Page 20: Warranty
(ii) misuse (including use inconsistent with written operating instructions for the product), mishandling, contamination, overheating, modification or alteration of the product by any customer or third party or (iii) use of replacement parts that are obtained from a party who is not an authorized dealer of Thermo Scientific prod- ucts.
