P.O. BOX 11846 TUCSON, AZ 85734
(520) 294-3292
• FAX (520) 741-2837
www.iotaengineering.com
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed, including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
CAUTION – To prevent electrical shock, do not mate unit connector until installation is complete and A.C. power is sup-
1.
plied to the unit.
2.
CAUTION – This fixture provides more than one power supply output source. To reduce the risk of electrical shock,
disconnect both normal and emergency sources by turning off the A.C. branch circuit and by disconnecting the unit
connector.
3.
CAUTION – This is a sealed unit. Components are not replaceable. Replace the entire unit when necessary.
CAUTION – Installation and servicing should be performed by qualified personnel only. De-energize before opening.
4.
The ILB-CP-HE-SD-XB is for use with grounded LED luminaires listed to UL standards. Not for use in heated air out-
5.
lets or hazardous locations.
6.
The ILB-CP-HE-SD-XB requires an unswitched A.C. power source of 120 to 277 volts AC, 50/60Hz.
The ILB-CP-HE-SD-XB and A.C. driver must be on the same branch circuit.
7.
8.
Do not mount near gas or electric heaters.
The ILB-CP-HE-SD-XB should be mounted in locations and at heights where it will not readily be subjected to tamper-
9.
ing by unauthorized personnel.
The ILB-CP-HE-SD-XB will supply 10-60VDC output at the individual rated specification for 90 minutes. See individual
10.
units for output specifications.
11.
The ILB-CP-HE-SD-XB is certified in the CA Title 20 Modernized Appliance Efficiency Database System (MAEDBS)
as a small battery charger.
12.
Suitable for use in damp locations and plenum spaces.
13.
Suitable for luminaires, recessed Type IC (intended for insulation contact).
14.
For use in 0° C minimum, 55° C maximum ambient temperatures.
15.
The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition, void war-
ranty, and result in non-compliance with UL specifications.
16.
Do not use this equipment for other than intended use.
17.
Install in accordance with the National Electrical Code and local regulations.
18.
Lighting fixture manufacturers, electricians, and end-users need to ensure product system compatibility before final
installation. See addendum for compatibility and covered luminaire requirements.
EMERGENCY LED DRIVER FOR USE
WITH LED LUMINAIRES IDENTIFIED
IN THE MANUFACTURER'S
INSTALLATION INSTRUCTIONS
E473237
INSTRUCTION MANUAL
SAVE THESE INSTRUCTIONS
ILB-CP-HE-SD-XB
LIGHTING EQUIPMENT FOR LED
WITH PUSH-IN CONNECTOR
Patented. See iotaengineering.com/patents for more details
HIGH EFFICIENCY PERFORMANCE
MEETS CA T20 BATTERY CHARGER
EFFICIENCY STANDARDS
EMERGENCY
HARNESS
Advertisement
Related Manuals for IOTA ILB-CP-HE-SD-XB
Summary of Contents for IOTA ILB-CP-HE-SD-XB
- Page 1 CAUTION – This is a sealed unit. Components are not replaceable. Replace the entire unit when necessary. CAUTION – Installation and servicing should be performed by qualified personnel only. De-energize before opening. The ILB-CP-HE-SD-XB is for use with grounded LED luminaires listed to UL standards. Not for use in heated air out- lets or hazardous locations.
- Page 2 The ILB-CP-HE-SD-XB is designed for use with most LED loads that operate at 10-60 VDC. The ILB-CP-HE-SD-XB has been evaluated to and found compliant to UL 924 STANDARD FOR SAFETY Emergency Lighting and Power Equipment. The as-installed performance of system must meet or exceed all Federal, State, and Local code requirements.
- Page 3 STEP 5 - WIRING THE AC INPUT The ILB-CP-HE-SD-XB requires an unswitched A.C. power source of 120 to 277 VAC, 50/60Hz for maintaining the emergency battery in a state of readiness regardless of local switch position; therefore when used with switched fixtures, the ILB-CP-HE-SD-XB unswitched AC input must be wired ahead of the switch.
- Page 4 OPERATION Normal Mode - A.C. power is present. The A.C. driver operates the LED load as intended. The ILB-CP-HE-SD-XB is in the standby charging mode. The TBTS will be flashing green providing a visual indication that the battery is being charged, or solid green if the battery is fully charged.
