Follow This Step-By-Step
Guide To Using Your Generator
1

Remove generator from package

2

2-Cycle Fuel Mix

3

Add Fuel

4

Start The Generator

Use the generator OUTDOORS in a WELL VENTILATED AREA.
DO NOT CONNECT electrical devices until AFTER the generator
is started.
Turn Engine Switch to ON
Turn FUEL PETCOCK to ON (Figure A)
Adjust the CHOKE to CLOSED/CHOKE position (Figure B)
Start the generator manually with the Recoil (Pull) Start.
Once the engine has started and runs for about a minute, move
the choke lever slowly towards the "Open/Run" position.
You can now connect electrical devices.
DO NOT CONNECT electrical devices until
AFTER the generator is started.
On
O
Fuel Petcock (Figure A)

WARNING

IF THERE IS ANY QUESTION ABOUT A
CONDITION BEING SAFE OR UNSAFE,
DO NOT OPERATE THIS PRODUCT!
Always follow Warning labels placed on the
generator, and read and follow all Warning
labels included inside the Product Manual.
WARNING: NEVER use a generator inside
a home or a garage, EVEN IF the doors
and windows are open.
ONLY USE OUTSIDE and far way from
windows, doors and vents leading into an
enclosed area.
Using a generator indoors can kill you in
minutes. The generator produces an
exhaust that contains carbon monoxide.
This is a poison you cannot see or smell.
Do not attach a chain or rope to secure the
generator to a post as this can be difficult to
remove in the event of an emergency.
TOLL-FREE NATIONWIDE HELP LINE! 866-460-9436
This generator includes
ATTENTION
a built-in Carbon Monoxide
Warning Alert! The generator
will automatically shut-off if
dangerous levels of Carbon
ALERT!
Monoxide is detected.
Use pre-blended Unleaded Gasoline and
2-cycle oil for outdoor power equipment
with 50:1 mix.
Maximum Capacity: 0.8 Gallon fuel tank
120V AC
AC Reset
Monday-Friday 8:00 AM - 4:00 PM Central Time
GEN1000
1,000 Surge / 900 Running Watts
Unleaded Gas & Mixed 2-Cycle Oil (50:1)

GENERATOR SPECIFICATIONS:

• 1-120 Volt AC Outlet
• Displacement: 72cc
• Phase: Single
• AC Voltage: 120V @ 60Hz
• Recoil Start
• Decibel Rating <65 db @ 24 Feet
• Complies with EPA emissions
• Engine Run Time: 5 Hours@50%Load
• Fuel Tank Capacity: 0.8 Gallons
• Fuel: Unleaded Gas & 2-Cycle Oil Mix (50:1)
• Warranty: 2 YEAR Limited Emissions
• Warranty: 1 YEAR Limited
• DO NOT use E85, gas/oil mix, or modify the
engine to run on alternate fuels.
• High Altitude Use: This generator is not
recommended for high altitude use 3,000 feet above
sea level.
• If you are using a generator at 3,000 feet above
sea level, the generator may not function properly
because of air flow getting through the carburetor.
OIL IS NOT INCLUDED WITH THIS
GENERATOR. IT IS SOLD SEPARATELY.
Read and understand instruction manual
before using generator.
2
Engine
Choke
Switch
(Figure B)
Need Help? Call Customer Service!
SPORTSMAN
SPORTSMAN
Add 2-Cycle Fuel
Fuel Petcock
(Figure A)
Recoil
Start
