GEN2000-SS
QJ
2000 Surge Watts / 1400 Running Watts
GAS FUEL GENERATOR INSTRUCTION MANUAL
READ ALL INSTRUCTIONS AND WARNINGS BEFORE USING THIS PRODUCT.
This manual provides important information on proper operation & maintenance. Every effort has been
made to ensure the accuracy of this manual. These instructions are not meant to cover every possible
condition and situation that may occur. We reserve the right to change this product at any time without
prior notice.
IF THERE IS ANY QUESTION ABOUT A CONDITION BEING SAFE OR UNSAFE,
DO NOT OPERATE THIS PRODUCT!
Visit our website for Troubleshooting / Frequently Asked Questions
http://sportsmanseriesbrand.com/generators
QUESTIONS? PROBLEMS? CALL US FIRST!
If you experience a problem, have questions or need parts for this product, call Customer Service at
1-866-460-9436, Monday-Friday, 8 AM - 4 PM Central Time. A copy of the sales receipt is required.
FOR CONSUMER USE ONLY – NOT FOR PROFESSIONAL USE.
KEEP THIS MANUAL, SALES RECEIPT & APPLICABLE WARRANTY FOR FUTURE REFERENCE.
Advertisement
Table of Contents
Related Manuals for Sportsman GEN2000-SS
Summary of Contents for Sportsman GEN2000-SS
- Page 1 GEN2000-SS 2000 Surge Watts / 1400 Running Watts GAS FUEL GENERATOR INSTRUCTION MANUAL READ ALL INSTRUCTIONS AND WARNINGS BEFORE USING THIS PRODUCT. This manual provides important information on proper operation & maintenance. Every effort has been made to ensure the accuracy of this manual. These instructions are not meant to cover every possible condition and situation that may occur.
- Page 2 GEN2000-SS Portable Gas Fuel Generator FEATURES: 2000 Surge Watts / 1400 Running Watts • 4-Stroke OHV Engine 94cc • Recoil Start • 3.5 HP Gas Fuel Engine • Spark Plug Model E7RTC • • 1 - 12V D/C Outlet • 2 - 120V A/C Outlets Engine Run Time: 11 Hours @ 50% Load •...
-
Page 3: Table Of Contents
Changing Fuel Line ..............................19 Spark Plug Maintenance ............................19 Emptying The Fuel Tank ............................19 STORAGE/TRANSPORT PROCEDURES ........................20 TROUBLESHOOTING ..............................21 PARTS DIAGRAM ................................22 WIRE DIAGRAM ................................27 EMISSION CONTROL SYSTEM WARRANTY ......................... 28 GEN2000-SS Portable Gas Fuel Generator... -
Page 4: Recognize Safety Symbols, Words And Labels
Parts replaced during warranty repairs will be considered as part of the original product and will have the same warranty period as the original product. This warranty gives you specific legal rights, and you may have other rights that vary state to state. GEN2000-SS Portable Gas Fuel Generator... - Page 5 Avoid the use of extension cords if possible. If you choose to use them, be sure they are sized adequately to handle the flow of electricity. An undersized cord can overheat, short out and cause a fire. Recommend that use high quality, UL-rated, well-insulated grounded extension cords that are intended for outdoors use. GEN2000-SS Portable Gas Fuel Generator...
- Page 6 • Do not operate an excessive number of electrical devices in excess of the wattage capacity of this generator. • Do not turn on electrical devices until after they are connected to this generator. • Turn off all connected electrical devices before stopping this generator. GEN2000-SS Portable Gas Fuel Generator...
- Page 7 GEN2000-SS Portable Gas Fuel Generator...
- Page 8 In addition to the previously described safety information, familiarize yourself with all safety and hazard placards on this generator. GEN2000-SS Portable Gas Fuel Generator...
-
Page 9: Package Contents
If there are missing items, call 1-866-460-9436, Monday - Friday, 8 AM - 4 PM Central Time for customer service. DO NOT RETURN THIS GENERATOR TO THE RETAILER. Item List: DC connector wires for charging 12 Volt automotive-type batteries Spark plug wrench Funnel for adding Oil GEN2000-SS Portable Gas Fuel Generator... -
Page 10: Components
5) Carburetor Choke Lever 6) Air Filter Cover 7) Recoil Starter 8) AC Circuit Protector 9) Engine Switch 10) 120 Volt AC Outlets 11) DC Circuit Protector 12) 12 Volt DC Outlet 13) Grounding Terminal 4) Fuel Cock GEN2000-SS Portable Gas Fuel Generator... -
Page 11: Preparing The Generator For Use
When the engine crankcase is full and almost overflowing, the oil level should reach the lower lip of the oil filling opening as shown in Figure 2. 4. Replace the oil filler/dipstick cap and close the oil access panel. Figure 1 – Unscrew the Dipstick Cap Figure 2 - Add Oil GEN2000-SS Portable Gas Fuel Generator... -
Page 12: Step 2 - Add Gasoline
• Avoid getting dirt and/or water in the fuel tank. • Gasoline can age in the fuel tank and make it difficult to start this generator. Never store this generator for extended time with gasoline in the fuel tank. GEN2000-SS Portable Gas Fuel Generator... -
Page 13: Step 3 - Ground The Generator
• Always allow several minutes for the engine to cool before refueling. • Do not overfill the fuel tank. Always check for fuel spills and immediately wipe them up. Spilled fuel is a fire hazard and causes environmental damage. GEN2000-SS Portable Gas Fuel Generator... -
Page 14: Step 3 - Ground The Generator
It can be opened and closed by operating the choke rod manually. Pull the rod out toward CLOSED to enrich the mixture for cold starting Figure 4 The Recoil Start is located on the front of the generator. GEN2000-SS Portable Gas Fuel Generator... -
Page 15: Using The Generator
120 Volt, single phase, 60 Hz loads to the 120 well water pump (1/3 HP) 1000 2000 Volt outlet. Connect 12 Volt, DC loads to the 12 Volt window air conditioner (10000 BTU) 1200 1800 outlet. window fan GEN2000-SS Portable Gas Fuel Generator... -
Page 16: Dc Usage
#8 wire #10 wire #12 wire #14 wire #16 wire 1000 1200 1800 1200 2400 1800 3600 2400 4800 3000 6000 3600 7200 4800 9600 Figure 6 - Maximum Extension Cord Lengths by Power Requirement GEN2000-SS Portable Gas Fuel Generator... -
Page 17: Stopping The Generator
4. Carefully remove the carbon deposits from the spark arrester screen with a wire brush. 5. Replace the spark arrester if it is damaged. 6. Position the spark arrester in the muffler and attach with the screws. GEN2000-SS Portable Gas Fuel Generator... -
Page 18: Checking The Oil Level
TROUBLESHOOTING: IF THE GENERATOR WILL NOT START, DOUBLE CHECK THAT THE OIL LEVEL IS COMPLETELY FULL AND ALMOST OVERFLOWING. Figure 8B – Adding oil Figure 8A – Use 10mm hex wrench to REMOVE bolt and drain oil GEN2000-SS Portable Gas Fuel Generator... -
Page 19: Air Filter Maintenance
To store this generator for extended time, the fuel needs to be drained from the carburetor. To drain the gasoline from the carburetor turn the fuel valve to the “off” position while the engine is running. The generator will shut down when all the gasoline in the carburetor has been used. GEN2000-SS Portable Gas Fuel Generator... -
Page 20: Storage/Transport Procedures
2 months to 1 year Empty the fuel tank. (See “Emptying the Fuel Tank” in the “Maintenance/Care” section.) 1 year or more Empty the fuel tank. (See “Emptying the Fuel Tank” in the “Maintenance/Care” section.) Disconnect the spark plug. GEN2000-SS Portable Gas Fuel Generator... -
Page 21: Troubleshooting
Generator runs but does not support all Short in one of the connected devices. Disconnect any faulty or short-circuited connected electrical devices. electrical loads. Air filter is dirty. Clean or replace air filter. GEN2000-SS Portable Gas Fuel Generator... -
Page 22: Parts Diagram
PARTS DIAGRAM GEN2000-SS Portable Gas Fuel Generator... - Page 23 GEN2000-SS Portable Gas Fuel Generator...
- Page 24 GEN2000-SS Portable Gas Fuel Generator...
- Page 25 GEN2000-SS Portable Gas Fuel Generator...
- Page 26 GEN2000-SS Portable Gas Fuel Generator...
-
Page 27: Wire Diagram
WIRING DIAGRAM GEN2000-SS Portable Gas Fuel Generator... -
Page 28: Emission Control System Warranty
(2) Any warranty part that is scheduled only for regular inspection in your Owner’s Manual is warranted for warranty period stated above. Any such part repaired or replaced under warranty will be warranted for the remaining warranty period. GEN2000-SS Portable Gas Fuel Generator... - Page 29 (a) Purge valves (b) Carbon canister (c) canister Mounting Brackets (d) Fuel Cap (e) Fuel Tank (7) Miscellaneous items used in above systems including: (a) Switches (b) Hoses, belts connectors, and assemblies (8) Air injection system (a) Pulse valve 201806 GEN2000-SS Portable Gas Fuel Generator...
