i
GEN2000
2,000 MAX WATTS INVERTER GENERATOR
INSTRUCTION MANUAL
R E A D A L L I N S T R U C T I O N S A N D W A R N I N G S B E F O R E U S I N G T H I S P R O D U C T .
This manual provides important information on proper operation & maintenance. Every effort has been made to ensure the accuracy of this manual. These instructions
are not meant to cover every possible condition and situation that may occur. We reserve the right to change this product at any time without prior notice.
I F T H E R E I S A N Y Q U E S T I O N A B O U T A C O N D I T I O N B E I N G S A F E O R U N S A F E , D O N O T O P E R A T E T H I S P R O D U C T !
D O N O T R E T U R N T H I S G E N E R A T O R T O T H E R E T A I L E R !
If you experience a problem, have questions or need parts for this product, call Customer Service at
1-866-460-9436, Monday-Friday, 8 AM - 4 PM Central Time. A copy of the sales receipt is required.
FOR CONSUMER USE ONLY – NOT FOR PROFESSIONAL USE.
KEEP THIS MANUAL, SALES RECEIPT & APPLICABLE WARRANTY FOR FUTURE REFERENCE.
CALIFORNIA PROPOSITION 65
WARNING:
This product, or the exhaust from this generator, may contain chemicals, including lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. Wash hands after handling.
2 YEAR LIMITED EMISSION-RELATED WARRANTY
THIS ENGINE MEETS U.S. EPA EMISSION STANDARDS UNDER 40 CFR 1054.625 .The emission-related limited warranty is valid for two (2) years. Keep the
purchase receipt and mail in the product registration card for proof of purchase. Buffalo Corp limits emission-related warranty repairs to authorized service centers for
owners located within 100 miles of an authorized service center. For owners located more than 100 miles from an authorized service center, Buffalo Corp will, in its sole
discretion, either pay for shipping costs to and from an authorized service center, provide for a service technician to come to the owner to make the warranty repair, or
pay for the repair to be made at a local non-authorized service center. The provisions of this paragraph apply only for the contiguous states, excluding the states with
high-altitude areas identified in 40 CFR part 1068, Appendix III.
To exercise this warranty, DO NOT RETURN TO RETAILER. Instead, call Customer Service toll free at 1-866-460-9436 (email address info@buffalotools.com) and
you will be instructed on where to take the engine for warranty service. Take the generator and proof of purchase (your receipt) to the repair facility recommended by the
Customer Service Representative. The warranty does not extend to generators damaged or affected by fuel contamination, accidents, neglect, misuse, unauthorized
alterations, use in an application for which the product was not designed and any other modifications or abuse.
1 YEAR LIMITED WARRANTY
(30 Day Limited Warranty for Commercial and Rental Purpose)
Generators are warranted to be free from defects in materials and workmanship for a period of 1 YEAR from date of original purchase. Buffalo Corp. is not liable for any
indirect, incidental or consequential damages from the sale or use of this product. Any implied warranties are limited to 1 YEAR as stated, or as otherwise stated, in this
written limited warranty. Some states do not allow the exclusion or limitation of incidental or consequential damages. Some states do not allow limitation on the length of
an implied warranty. Buffalo Corp will repair or replace, at its discretion, any part that is proven to be defective in materials or workmanship under normal use during the 1
YEAR warranty period. Warranty repairs or replacements will be made without charge for parts or labor. Parts replaced during warranty repairs will be considered as
part of the original product and will have the same warranty period as the original product. This warranty gives you specific legal rights, and you may have other rights
that vary state to state.


1

Advertisement

Table of Contents
loading

Summary of Contents for Sportsman GEN2000i

  • Page 1 GEN2000 2,000 MAX WATTS INVERTER GENERATOR INSTRUCTION MANUAL R E A D A L L I N S T R U C T I O N S A N D W A R N I N G S B E F O R E U S I N G T H I S P R O D U C T . This manual provides important information on proper operation &...
  • Page 2: Important Safety Instructions

    Notice Regarding Emissions: Engines certified to comply with California and U.S. EPA emission regulations for SORE (Small Off Road Equipment) are certified to operate on regular unleaded gasoline and may include the following emission control systems: Three- Way Catalyst (TWC) (if equipped), and Engine Modifications (EM). Legal Requirements: Federal and/or State Occupational Safety and Health Administration (OSHA) regulations, local codes, and/or ordinances may apply to the intended use of this generator.
  • Page 3 Flammable Gasoline: This generator may emit highly flammable and explosive gasoline vapors, which can cause severe burns or even death. A nearby open flame can lead to an explosion even if not directly in contact with gasoline. • Do not operate this generator near open flame. •...
  • Page 4 This generator produces powerful voltage, which can result in electrocution. Powerful Voltage: • ALWAYS ground this generator before using it. (See “Ground the Generator” section in this manual). • Only electrical devices should be plugged into this generator, either directly or with an extension cord. NEVER connect a building electrical system to this generator without a qualified electrician.
  • Page 5 Usage: Misuse of this generator can damage it or shorten its life. • Use this generator only for its intended purpose. • Operate this generator only on a dry, level surface. Do not secure the generator with a chain or rope, which would prevent it from being moved in an emergency.
  • Page 6 FEATURES: •1.0 Gallon Fuel Tank •2,000 Watts Max AC output •4,500 RPM •99cc, 4 stroke •Low oil shutdown •Recoil Start •Run Time : 4.5 Hours at 50% load •Noise Level : 60db at 0% This  is a Gasoline Powered Invertor Generator  that  offers  clean  power  for  electronics. 1)...
  • Page 7: Check Engine Fuel

    CHECK ENGINE FUEL l Make sure there is sufficient fuel in the tank. l If fuel is low, refill with unleaded automotive gasoline. Be sure to use the fuel filter screen on the fuel filter neck. l l Recommended fuel: Unleaded gasoline. Fuel tank capacity: 1.0 Gallon (3.7 Liters) l...
  • Page 8: Stopping The Engine

    7. Turn the choke lever back to RUN position then plug in appliances. USING ELECTRIC POWER AC APPLICATION (a) Turn off the switch(es) of the electrical appliance(s) before connecting to the generator. Insert the plug(s) of the electrical appliance(s) into the receptacle. l...
  • Page 9: Engine Oil Replacement

    necessary Choke Check choke operati o n l Val v e Check and adj u st when engi n e i s col d . l Cl e arance Fuel Li n e Check fuel hose for crack or damage. l...
  • Page 10: Cleaning And Adjusting Spark Plug

    l Engine Oil SAE 10W30 Capacity: 25 oz. l Be sure no foreign material enters the crankcase. Do not tilt the generator when adding engine oil. This could result in overfilling and damage to the engine l l Clean the oil filter every other 100 hr. WASHABLE AIR FILTER Maintaining an air cleaner in proper condition is very important.
  • Page 11: Troubleshooting

    4. Remove the carbon deposits on the muffler screen and spark arrester using a wire brush. 5. Install the muffler screen. 6. Install the cover TROUBLE SHOOTING Engine won’t start 1. Fuel systems No fuel supplied to combustion chamber. l No fuel in tank….
  • Page 12 5. The generator must remain in a vertical position. MODEL GEN2000i Type Inverter Generator 60Hz 120V AC Voltage Max. Output 2.0 kW Rated Output 1.7 kW Power Factor DC Output 12V / 5.0A Model XY152F-4 Type Air-cooled, 4 cycle, OHV, Gasoline Engine Bore×Stroke mm×mm...
  • Page 13: Storage Instructions

    STORAGE INSTRUCTIONS Rotate gas valve to “OFF” position.         Remove three screws from engine air box   to locate carburetor.           Remove drain screw from side of carburetor   Fuel will begin to drain out of bowl  ...
  • Page 14 WIRING   D IAGRAM            ...
  • Page 15    ...
  • Page 16    ...
  • Page 17    ...
  • Page 18    ...
  • Page 19    ...
  • Page 20    ...
  • Page 21    ...
  • Page 22    ...
  • Page 23 3                            ...
