Super X12SPi-TF User's Manual

Quick Reference Table

Jumper
JBT1
JPME1
LED
LE4
LEDBMC
LEDPWR
UID-LED
Connector
COM1
FAN1 ~ FAN5, FANA, FANB
I-SATA0 ~ I-SATA7
IPMI_LAN
JF1
JI2C_EXP1
JI2C_FP1
JIPMB1
JL1
JNCSI1
JNVI C1
2
JPI C1
2
JPWR1
JPWR2
JPWR3
JRK1
JSD1, JSD2
JSTBY1
LAN1, LAN2
M.2-H
NVME0/1
SLOT1
SLOT2
SLOT4, SLOT6
SLOT7
S-SATA0, S-SATA1
S-SGPIO
Note: Table is continued on the next page.
Description
CMOS Clear
ME Recovery
Description
M.2 LED
BMC Heartbeat LED
Onboard Power LED
Unit Identifier (UID) LED
Description
COM Header
CPU/System Fan Headers
Intel® PCH SATA 3.0 Ports (with RAID 0, 1, 5, 10)
Dedicated IPMI LAN Port
Front Control Panel Header
SMBus I C for Expander
2
SMBus I C for LCD Devices
2
4-pin BMC External I C Header (for an IPMI card)
2
Chassis Intrusion Header
NC-SI Header for IPMI Support
NVMe I C Header
2
Power System Management Bus (SMB) I
8-pin Power Connector
4-pin Power Connector
24-pin Power Connector
Intel RAID Key Header
SATA DOM Power Connectors
Standby Power Header
Dual 10G Base-T Ports
M.2 M-Key 2280/22110 (supports PCIe 3.0 x4/SATA3) Slot
PCIe 4.0 x8 Slimeline SAS Connector
CPU PCIe 4.0 x 8
CPU PCIe 4.0 x8 (IN x 16)
CPU PCIe 4.0 x16
CPU PCIe 4.0 x8
SATA 3.0 Ports with SATA DOM Power
Serial Link General Purpose I/O Connection Header
12
Default Setting
Open (Normal)
Pins 1-2 (Normal)
Status
Blinking Green: Device Working
Blinking Green: BMC Normal
Solid Green: Power On
Solid Blue: Unit Identified
C Header
2
