Super X12SPi-TF User's Manual
SATA Port 0-7 SATA Device Type
Use this feature to specify if the SATA port specified should be connected to a Solid State
Drive or a Hard Disk Drive. The options are Hard Disk Drive and Solid State Drive.
PCH sSATA Configuration

sSATA Controller
This feature enables or disables the onboard SATA controller supported by the Intel PCH
chip. The options are Enable and Disable.
Configure sSATA as
Select AHCI to configure an sSATA drive specified as an AHCI drive. Select RAID to configure
an sSATA drive specified as a RAID drive. The options are AHCI and RAID.
*If the feature above is set to RAID, the sSATA RSTe Boot Info and sSATA RAID Option
ROM/UEFI Driver are available for configuration:
sSATA RSTe Boot Info
Select Enable to provide full int13h support for the devices attached to sSATA controller. The
options are Disable and Enable.
Support Aggressive Link Power Management
When this feature is set to Enable, the SATA AHCI controller manages the power usage of
the SATA link. The controller puts the link in a low power mode during extended periods of
I/O inactivity, and returns the link to an active state when I/O activity resumes. The options
are Disable and Enable.
sSATA RAID Option ROM/UEFI Driver
Select UEFI to load the EFI driver for system boot. Select Legacy to load a legacy driver for
system boot. The options are Disable, EFI, and Legacy.
sSATA Port 0/1/2
This feature displays the information detected on the installed SATA drive on the particular
SATA port.
•
Software Preserve Support
sSATA Port 0/1/2 Hot Plug
Set this feature to Enable for hot plug support, which allows you to replace a SATA drive
without shutting down the system. The options are Disabled and Enabled.
sSATA Port 0/1/2 Spin Up Device
Set this feature to enable or disable the PCH to initialize the device. The options are
Disabled and Enabled.
