This Quick Guide is intended to help you un-
derstand the operation of the TENS unit faster,
but it cannot take the place of the user man-
ual. Be sure to read the user manual before
use so you are aware of any contraindications
and warnings. If you're not sure whether this
device is suitable for you, consult your doctor
first.
Note: Do not use it while charging.
1. Clean the applica-
tion areas.
Quick Guide
Attention
Operation
2. Connect the lead
wire to a pair of
electrode pads and
the device(keep the
unit off).
Advertisement
Table of Contents
Related Manuals for Auvon USER MANUAL
Summary of Contents for Auvon USER MANUAL
- Page 1 TENS unit faster, but it cannot take the place of the user man- ual. Be sure to read the user manual before use so you are aware of any contraindications and warnings. If you’re not sure whether this device is suitable for you, consult your doctor first.
- Page 2 3. Paste the pads to 4. Turn on the the skin firmly. device. 5. Choose a mode 6. Adjust intensity. and sub-mode.
- Page 3 8. Lock / Unlock the screen by holding 7. Set time. the center button for 3 seconds. 10. Remove the pads 9. Turn off the device (do not pull the after massage. wire).
- Page 4 Pad Placement Suggestion Notes: 1. Do not use the unit in the shower, sleeping, driv- ing, operating machinery, or during any electrical- ly-stimulated activity. 2. The electrode pads should not be overlapped nor placed on the artery, broken skin, or on the same side of the arm/leg.
- Page 5 USER MANUAL TENS & EMS Device Relaxation, Anywhere, Anytime Model AS1080 Device Name: TENS & EMS Device...
-
Page 6: Table Of Contents
TABLE OF CONTENTS 1. Explanation of TENS ........7 2. Standard Package ..........7 3. Illustrations of the Device ......... 8 4. Operating Instructions ........10 4.1 Note Before Use ........10 4.2 How to Use ..........10 4.3 After Use ..........15 4.4 Charge the Battery ......... -
Page 7: Explanation Of Tens
(leg) due to strain from exercise or normal household work activities. 2. Standard Package ● AUVON TENS & EMS Massager ® ● Pin Pads ● Pads Holder ● Pouch ● Set of Electrode Wires(1/2 Wire) ● USB-C Port ● User Manual... -
Page 8: Illustrations Of The Device
Email： support@iauvon.com 3. Illustrations of the Device... - Page 9 Email： support@iauvon.com Massage Time ① Knead Modes ② Cupping Modes ③ Deep Tissue Modes ④ Mode Selection ⑤ Intensity Decrease (-) ⑥ Time Selection ⑦ Acupuncture Modes ⑧ Tapping Modes ⑨ Scraping Modes ⑩ Adjustable Intensity ⑪ Intensity Increase (+) ⑫...
-
Page 10: Operating Instructions
Email： support@iauvon.com 4. Operating Instructions 4.1 Note Before Use ● Do not use this device during charging. ● When the device has no output and no operation, it will shut down automatically in 5 minutes. ● You may experience tingling, trembling, or muscle pulling when using the device depending on the mode you choose, so please try out all the modes and select the one that's most comfortable for you. - Page 11 Email： support@iauvon.com 2. Take out the pads from the sealed packaging and keep the packaging for future storage. 3. Connect one pair of electrode pads to one lead wire and plug the other end of the wire into the A or B output of the device.
- Page 12 Email： support@iauvon.com 4. Grab the corner of the electrode pad and peel it off the protective film, and do not pull the wire directly. Attach one pair of electrode pads to the massage area and press the edge of the elec- trode pads firmly on your skin to make sure full contact.
- Page 13 Email： support@iauvon.com 6. Press the M button to choose a mode. Then press the center button t o c h o o s e a s u b mode. NOTE: The intensity of the channel will revert to the lowest setting with each mode selection.
- Page 14 Email： support@iauvon.com 8. Use the “T” button you can set the massage time from 10-60 minutes. The time remaining is automatically counted down. Then the unit will automatically turn off af- ter time is finished. NOTE: It is recommend- ed that each area should not use this device for more than 30 minutes at a time.
-
Page 15: After Use
Email： support@iauvon.com 10. Press and hold the Center button for 3 sec- onds to lock the device, then the intensity, mode, and time can’t be ad- justed. Press the center button for 3 seconds a g a i n t o u n l o c k t h e screen. -
Page 16: Charge The Battery
Email： support@iauvon.com 4.4 Charge the Battery 1. When the battery icon shows “ ” or the mas- sage strength decreases, it indicates that the battery needs to charge. Turn off the unit. 2. Connect the device and the charger with a USB extension cord. - Page 17 Email： support@iauvon.com Main Mode Pulse Rate Pulse Mode Number (Hz) Width (μs) 2.7-30 1.6-13.7 41.6 5-20-5 10-55 2.7-32...
-
Page 18: Pad Placement Suggestion
Email： support@iauvon.com 5.2 Pad Placement Suggestion Neck Pain Shoulder Pain Modes: 1, 2, 3, 4, 8, 15, Modes: 5, 16, 17, 18 16, 19 Carpal Tunnel Syn- Tennis Elbow drome Modes: 5, 6, 10, 16 Modes: 1, 4, 7, 22 Back Pain Sciatica Modes: 8, 13, 14, 15, 16,... - Page 19 Email： support@iauvon.com Hip/Thigh Pain Period Pain Modes: 1, 2, 3, 4, 6, 7, 12, Modes: 13, 14, 19 15, 20 Knee Pain Claf Pain Modes: 9, 11, 12, 17, 21, Modes: 1, 2, 3, 4, 6, 7, 23, 24 Ankle Pain Plantar Fasciitis Modes: 3, 5, 15 Modes: 1, 2, 3, 4...
-
Page 20: Tens Electrode Pads & Pads Holder
Email： support@iauvon.com 6. TENS Electrode Pads & Pads Holder 6.1 Features High-quality ABS material to make sure you use it safely. Widely compatible for pads in different sizes. The salient points are designed specially to lessen damage to the pads. -
Page 21: Instruction
Email： support@iauvon.com 6.2 Instruction Stick the electrode pads on the holder to Step 1 avoid getting dust. Wind the thread around the holder for Step 2 easy use as shown. -
Page 22: Electrode Pads Care And Storage
Email： support@iauvon.com Step 3: Store the electrodes in the storage Step 3 bag and reseal the bag tightly. 6.3 Electrode Pads Care and Storage ●Do not cover the sticky side of the electrode pads with subjects like dry paper or dust, if you do, please drop a few drops of water and clean with finger pulp to remove dirt. -
Page 23: Electrode Pads Precautions
Email： support@iauvon.com ● Please store the electrode pads in a cool (between 5°C-35°C/41°F-95°F) and dry place. Do not expose the electrode pads to sunlight or any extreme tem- peratures to prolong the lifespan of the electrode pads. ● When the electrode pad has the following condi- tions, please do not use it and promptly replace it: gel melting;... -
Page 24: Safety Precautions & Warnings
Email： support@iauvon.com and the gel may be damaged when separating. The electrode pads should be at least one inch apart from each other. Changing the distance between the elec- trode pads or the orientation of the electrode pads can change the electrical sensation. 4. -
Page 25: Prohibited Individuals
Email： support@iauvon.com 7.2 Prohibited Individuals ● Pregnant women, infants and children. ● People who do not have the ability to express their thoughts or intentions. ● People who are incapable of operating the device by themselves. ● People who have a tendency to bleed internally after an injury or fracture. -
Page 26: Prohibited Activities
Email： support@iauvon.com 7.4 Prohibited Activities ● Shower or bath. ● Sleeping. ● Driving or operating machines. ● Exercising. ● Any activities that cannot be interfered with. 8. Trouble Shooting If your device is not operating properly, please check below for common problems and suggested solu- tions. - Page 27 Email： support@iauvon.com Possible Problem Solution Cause Different body Try to change the position of areas react the electrode pads. differently. One pad feels stronger than the other. Plug the wire into the output Poor wire port completely. If it does not connection.
- Page 28 Email： support@iauvon.com Possible Problem Solution Cause Charge the battery and a full Low battery. charge may need 2-3 hours. The device is Unplug the charging cable charging. and then turn it on again. The de- vice can’t turn on. The power The button may be stuck, button cannot please shake the body, and...
-
Page 29: Features
Email： support@iauvon.com Possible Problem Solution Cause Excessive usage Reduce the application time time or the or decrease the intensity. intensity The skin is too high. turns red or the When the pad has the follow- skin feels The electrode ing conditions, please do not irritated. -
Page 30: Symbols
Email： support@iauvon.com 63.4grams. Weight Atmosphere Pressure: Operating 700Hpa~1060Hpa. Condition There may be a +/-5% tolerance of all parameters and +/-20%tolerance of Remark amplitude & voltage. 10. Symbols Symbol Meaning Attention, consult accompanying documents BF Isolated Applied Part Class II equipment Disposal in accordance with Directive 2002/96/EC MANUFACTURER... -
Page 31: Certification
Meaning Date when the medical device was manufac- tured. Pls read the user manual before use IIIP Classification: The first number 2: Protect- ed against access to hazardous parts with a finger, and the jointed test finger of 12 mm Ф,... -
Page 32: Customer Service
Email： support@iauvon.com 12. Customer Service 24-Month Limited Warranty Lifetime Technical Support +1(678)829-7256 support@iauvon.com Auvon-US-AS1080-24mode-sms-v1.0-220726...
Need help?
Do you have a question about the USER MANUAL and is the answer not in the manual?
Questions and answers
Please help
how to remove & store pads
To remove and store Auvon electrode pads:
1. Turn off the device by pressing the power button for a few seconds.
2. Grab a corner of the electrode pad and slowly peel it away from the skin. Do not pull the wire, and avoid touching the gel.
3. Place the sticky side of the pad on the transparent film or pad holder.
4. Gently remove the lead wire connector from the electrode pads.
5. Store the electrode pads in the storage bag and reseal tightly to prevent drying out.
6. Keep them at room or cool temperature (5°C-35°C/41°F-95°F) and away from direct sunlight.
7. Organize the wires with a cable tie and store everything in the pouch.
