Reference Designator Part Type
U3 ADA4841-1YRZ
U4 ADM6711
U5 ADR445
U6 ADP3330
U7 ADG3301
U8 ADP3330
U9 ADP3330
U10 ADP3330
U11 ADP3330
U12 7408
U13 NC7S08
Y1 OSC-8DIP
Value Footprint
SO8NB
N/A SC70-4(LARGE_PIN_2)
SO8NB
SOT23-6
SOT23-6
SOT23-6
SOT23-6
SOT23-6
SOT23-6
TSSOP-14
SOT23-5
1MHz OSC_DIP8
Rev. PrA | Page 19 of 20
EVAL-AD7766/AD7767
Supplier No.
ADA4841-1YRZ
ADM6711ZAKSZ
ADR445ARZ
ADP3330ARTZ-5 (L8B)
Do not insert
ADP3330ARTZ-2.5 (L1B)
ADP3330ARTZ-2.5 (L1B)
ADP3330ARTZ-5 (L8B)
ADP3330ARTZ-2.5 (L1B)
FEC 1102978
Do not insert
Digikey CTX180-ND
