Analog Devices EVAL-AD7766 Preliminary Technical Data page 17

Preliminary Technical Data
Reference Designator Part Type
C103 CAP+
C104 CAP
C105 CAP+
C106 CAP
C107 CAP+
C108 CAP+
C109 CAP
C110 CAP+
C111 CAP+
D5 DIODE-S2M
D6 DIODE-S2M
F1 EMC_FILTER
F2 EMC_FILTER
F3 EMC_FILTER
F4 EMC_FILTER
F5 EMC_FILTER
F6 EMC_FILTER
F7 EMC_FILTER
F8 EMC_FILTER
F9 EMC_FILTER
F10 EMC_FILTER
F11 EMC_FILTER
J1 CON\41612\96
J2 SMA
J3 CON\POWER
J4 XLR-FEMALE
J5 SMB
J6 SMB
J7 SMB
J8 SMB
J9 PROBE
J10 SMB
J11 PROBE
J12 CON\POWER3
J13 CON\POWER
J15 SMA
L1 IND
L2 IND
L3 IND
L4 IND
L5 IND
L6 IND
L7 IND
L8 IND
L9 IND
L10 IND
LK1 JUMPER-2
LK2 JUMPER-2
LK3 JUMPER-2
R1 RES
R2 RES
Value Footprint
10uF CAP\TAJ_B
0.1uF 603
10uF CAP\TAJ_B
0.1uF 603
10uF CAP\TAJ_B
10uF CAP\TAJ_B
1nF 603
10uF CAP\TAJ_B
10uF CAP\TAJ_B
DO-214AA
DO-214AA
EMC_FILTER
EMC_FILTER
EMC_FILTER
EMC_FILTER
EMC_FILTER
NFM61R
NFM61R
EMC_FILTER
NFM61R
NFM61R
NFM61R
DIN41612-96
SMA
CON\POWER
XLR-FEMALE
SMA
SMA
SMA
SMA
PROBE
SMA
PROBE
CON\POWER3
CON\POWER
SMA
Ferrite Bead 603
Ferrite Bead 603
Ferrite Bead R0603
Ferrite Bead R0603
Ferrite Bead 603
Ferrite Bead R0603
Ferrite Bead 603
Ferrite Bead R0603
Ferrite Bead R0603
Ferrite Bead R0603
JUMPER_2_SWAP_AB
JUMPER_2_SWAP_AB
JUM_2_SWP_INV_AB
1K (0.001) 603
1K (0.001) 603
Rev. PrA | Page 17 of 20
EVAL-AD7766/AD7767
Supplier No.
FEC 197427
FEC 753567
FEC 197427
FEC 753567
Do not insert
Do not Insert
FEC 722170
Do not Insert
Do not Insert
FEC 646-982
FEC 646-982
FEC 9528202
FEC 9528202
FEC 9528202
FEC 9528202
FEC 9528202
FEC 9528202
FEC 9528202
FEC 9528202
FEC 9528202
FEC 9528202
FEC 9528202
FEC 104-986
FEC 1019324
FEC 151-785
FEC 724518
FEC 1019324
FEC 1019324
FEC 1019324
FEC 1019324
FEC 1019324
FEC 151-786
FEC 151-785
FEC 1019324
Short pads/solder
Short pads/solder
Short pads/solder
Short pads/solder
Short pads/solder
Short pads/solder
Short pads/solder
Short pads/solder
Short pads/solder
Do not Insert
Default to B
Default to B
Default to A
FEC 4628846
FEC 4628846
